0.75KW Motor Speed Control Inverter For Three Phase Pumps

0.75KW To 110KW Variable Speed Motors 50HZ To 60HZ Converter For Three Phase Pumps

Quick Details:

Rated Power: 0.75kw-110kw

Rated Voltage: 3 phase 380v

Rated Frequency: 50hz/60hz

Weight: 1.5kg-40kg

Input: 50/60hz

Output:0-300hz

Certificate: CE

Application: Printing industry and packing industry

Control Mode; V/F Control

Advantage Features:

1. Independent air duct for heat dissipation

Effectively prevent external dust, oil, and other pollution from entering the interior of the product.

2. Quick acceleration and deceleration

Excellent wave-by-wave current limiting, short-circuit protection, over-current protection, and over-voltage protection to ensure long-term stable operation of the product.

3. Rigorous EMC/EMI design and testing

Tested by a variety of equipment to ensure stable operation of the product in various electromagnetic environments and minimal interference with the external environment.

4. New design

Using 4-layer PCB board and a new generation of IGBT module technology, and mostly using IC integrated electronics so that 80% reduction in installation area and 20% reduction in volume.

5. Adopt the latest Texas Instrument’s high-speed chips

6. Large low-frequency torque, smoothly output

7. Maximum frequency up to 3000Hz, can be used in different machines.

Operating Panel

Mark	Key Name	Function
MENU	Program/Exit key	1. Enter or exit the programming state 2. Modify the data and abandon the storage 3. Switch fault display to stop/running parameter with the SHIFT key, press MENU to switch back to fault display state
ENT	Identify key	1. Edit function code parameters 2. Data storage confirmation 3. View the single group of parameters circularly
M	Multi-function key	Switch selection according to function
SHIFT	The shift key	1. Move the editing bit of function parameters 2. Move the data editing bit 3. Switch the display parameters of the operation panel under shutdown/running state
Increase Decrease	Add keys clockwise	In shutdown/operation state, the frequency value increases
Increase Decrease	Counterclockwise decrease key	The frequency value decreases under shutdown/running state
RUN	Run key	1. Long press the 3S operation panel to start the driver in the given mode 2. Long press 3S to set parameters, and then start the driver for parameters self-learning
STOP/AST	Stop/reset key	1. Press the button for 1S to report the fault and reset the fault after abnormal shutdown 2. Press for 1S to control the drive shutdown under the given mode of operation panel operation command

Details Image:

Application Case

VFDs for industrial washing machine

Advantage:

1. Large low-frequency torque

2. High-frequency acceleration time is short

3. High-frequency dehydration motor current sound is small, weak magnetic control effect is good.

CNC Machine Tools

Advantages of VFD

1. Short acceleration and deceleration time

2. Low noise in the process of motor operation

3. Long time running motor temperature is low

4, Low-frequency torque is large, high-frequency speed is stable

FAQ

1. Who are we?
We are a manufacturer based in Guangdong, China, start from 2009, sell to Domestic Market(100.00%). There are total about 201-300 people in our office.

2. How can we guarantee the quality?
Always a pre-production sample before mass production; Always final Inspection before shipment.

3. What can you buy from us?
Ultrasonic Generator, PLC/Motion Controller, Servo Motor And Stepper Motor, Frequency Converter, Automation System Development And Complete Set Of Electric Box.

4. Do you offer customization services?
Yes, we can customize the products according to your requirements. Please send us an inquiry, your inquiry will be replied within 12 hours.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, DDP, DDU, Express Delivery；
Accepted Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, CNY;
Accepted Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash;
Language Spoken: English, Chinese.

Product Tags:


*From:	Your email address is incorrect!
*To:	Guangdong Jiesheng Electric Technology Co., Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Motor Frequency Inverter
Brand Name:	STABLECU
Model Number:	ST310-4T0.75GB
Certification:	CE
Place of Origin:	China
MOQ:	1PCS
Price:	$88-$1288
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10000 pcs per month
Delivery Time:	5-8 days
Packaging Details:	1pcs/Polybag,100pcs/big polybag, 300pcs/ctn
Material:	ABS+PC
Power:	0.75KW
Voltage:	380V
Phase:	3 Phase
Color:	Huawei Gray
Type:	AC/AC Converters
Machine Case:	Aluminum coated zinc plate,cold rolled plate powder spraying
IGBT:	Infineon
