| Categories | Beans Color Sorter |
|---|---|
| Brand Name: | WENYAO |
| Model Number: | WYCS1-32 |
| Certification: | CE & ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 PCS |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200PCS Per Month |
| Delivery Time: | 7-10 work days |
| Packaging Details: | Plywood case package Packing size(L*W*H):0.63x1.05x1.49M |
| Produnct name: | Bean color sorter machine |
| Sorting accuracy(%): | ≥99.99 |
| CCD sensor: | Toshiba from Japan |
| Pixel: | 5400 |
| Ejector: | 16pcs nozzles |
| Capacity: | 300-500kg/h |
| port: | Shanghai,Ningbo,Tianjing,Guangzhou |
| Hopper: | Stainless 304 stell |
| Warranty: | 2 Years |
| After-sales service provided: | 7*24h on line support |
| Company Info. |
| Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Mini 32 Channels Coffee Bean Color Sorter Green / Roasted Coffee Bean Sorting Machine
What is color sorter?
Color sorter is a machine which used for separating the bad grain from the raw material through the color difference between the rejection and finished products. WY series of color sorter adopting 5400 pixel high resolution CCD camera, advanced image analysis and processing technology, long-life high-efficiency easy maintenance ejector as well as excellent optical system.
Diagrammatize Working Principle:
Technical Parameters:
| MODEL | WYCS1-32 |
| Chutes/Channels | 1/32 |
| Throughput(t/h) | 300-500kg/h |
| Sorting Aaccuracy | ≥99.99% |
| Power | 0.5kw |
| Power Voltage | 180-240V/50Hz |
| Air Source Pressure | 0.6-0.8Mpa |
| Air Consumption | <0.3M3/Min |
| Weight | 180kg |
| Diamension(L*W*H) | 460*895*1356mm |
Features:
1. It adopts high quality special industrial lenses;
2. Self checking system,5400 CCD camera, and photo processing technology.
3. High speed FPGA technology signal processor with fast detection and high identification rate.
4. Overall unit adopts intelligent closed-loop control.
5. High speed air value is used to ensure quick response, low power consumption and long service life.
6. It uses intelligent temperature and air pressure control technology in order to ensure the best operative mode for the whole machine.
7. Failure alarm automation and modular construction makes easy repair.
8. Combining LED lighting systems with fixed backgrounds and low voltage vibrator, auto-adjusts varying light levels, minimizing vibrations and producing consistent throughput across the chute.
Product Application:
Color sorters are mostly used in sorting grain (agricultural products). The rice sorting industry is the first big market. The rice sorting technology is according to the color differences of rice materials, using a high-resolution CCD optical sensor to separate stones, black rice, etc. It is the final step after polishing rice with a rice polisher. The second sorting market is in use for coarse cereals, such as wheat, corn, peanut, different kinds of beans, sesame seeds, etc. This can also include grains, seeds, cereals, pulses, coffee, and nuts. The color sorters also can be used to remove harmful plastics and metals.
Optical Color Sorters are among the newest technology in seed and grain processing. This equipment separates particles based on color and is often found at or near the end of the processing line, after mechanical separations, to remove impurities of similar size and density.
Machines are available from one to ten chutes wide. Technology range includes a simple monochromatic version, to bichromatic, NIR, InGaAs, RGB Full Color, and shape sizing.
Color sorting is necessary nowadays to ensure the best purity of bulk products, as well as ensuring that the strictest food hygiene and health requirements of end-products are met.
Sorting effect for coffee bean:
Packing delivery:
FAQ:
1.Q:How long about the guarantee period?
Tow year. And we will supply lifelong software upgrade services for
our customers.
2.Q:Will you accept L/C as payment?
L/C ,T/T is OK.
3.Q:How about engineers service oversea?
Our engineers could go abroad services when necessary.
4.How about the sample machines for testing?
Sample sending for testing is welcomed. Or you send these three
photos, the raw material, good material (which is you want), bad
material (which is you want to discard). We send our video to you.
5.Q:How to use the machine?
We will supply the Installation instructions or video and our
engineers will train your operators.
6.Can you supply the accessories parts of color sorter?
Yes,we can supply some spare parts when you need.
7. Which machine will work together with our color sorter which you
can supply?
We can provide Air compressor, air tank, air filters, Cleaning
brushes, etc.
