ASTM 316L Stainless Steel Round Bar S31603 High Strength

Categories Stainless Steel Round Bar
Brand Name: ANSTEEL,TISCO,BAOSTEEL,PANGANGGROUP
Model Number: ASTM 301L,UNS S30103
Certification: SGS,TUV,BV,ISO,MTC
Place of Origin: China
MOQ: 450kg or Negotiations
Price: 2110-3110 USD/Ton or Negotiations
Payment Terms: T/T
Supply Ability: 130000KGS/Month
Delivery Time: Ex-stock for delivery: 4-7 days Production lead time: 28-60 days
Packaging Details: Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name: ASTM 316L Stainless Steel Round Bar
Executive Technical Standard: ASTM,UNS,DIN EN,BS EN,ISO/TS etc.
Grades: ASTM 316L,UNS S31603,X2CrNiMo17-12-2,1.4404
Processing methods: Machined etc.
Heat treatment condition: Annealed etc.
Surface: Black,Bright etc.
Profile: Round Bar,Flat Bar,Forging Parts,Sheets Plates etc.
Price Term: Ex-work, FOB, CIF, CFR, DDU etc.
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

ASTM 316L Stainless Steel Round Bar S31603 High Strength

ASTM 316L Stainless Steel Round Bar S31603 Round Bar X2CrNiMo17-12-2 1.4404 Bar


Description


Our company provides ASTM 316L Stainless Steel Round Bar UNS S31603 Forged X2CrNiMo17-12-2/1.4404 VOD ASTM A959-2004.

All of ASTM 316L Stainless Steel Round Bar UNS S31603 Forged X2CrNiMo17-12-2/1.4404 VOD ASTM A959-2004 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.


  • Material:Metal,Stainless Steel Round Bar,316L/S31603,X2CrNiMo17-12-2/1.4404,SUS 316L,STS 316L,316S11.
  • Shape:Stainless Steel Round Bar.ASTM 316L Stainless Steel Round Bar S31603 Round Bar X2CrNiMo17-12-2 1.4404 Bar
  • Round bar / Wire rod (Diameter): 5.5mm to 800mm

Products Details


ASTM 316L Stainless Steel Round Bar UNS S31603 Forged X2CrNiMo17-12-2/1.4404 VOD ASTM A959-2004

Chemical Composition (weight%):Mechanical Properties Under Final Heat Treatment:
C (%): ≤ 0.030
Si (%): ≤ 1.00
Mn (%): ≤ 2.00
P (%)≤: 0.045
S (%)≤: 0.030
Cr (%): 16.0~18.0
Ni (%): 12.0~15.0
Mo (%): 2.00~3.00
N (%): -
Condition: solution treated
Heat treatment temperature /℃: 1010~1150
Medium: rapid cooling
σb/≥ MPa: 480
σ0.2/≥ MPa: 175
δ ≥(%): 40
ф ≥ (%): 60
Hardness | HB ≤: 217


Applications:


Pulp mill bleach systems
Seawater handling equipments
Tall oil distillation columns and equipments
Food processing equipments
Hydrometallurgy, heat exchangers
Oil and gas production equipments


Technical StandardEquivalent Grade
ASTM A959(2004)

316L/S31603

BS 977-1(1996)316S11
BS EN 10088-2(2005)X2CrNiMo17-12-2
NF EN 10088-2(2005)X2CrNiMo17-12-2
DIN EN 10088-2(2005)X2CrNiMo17-12-2/1.4404
KS D3706(2006)STS 316L
JIS G4303(2005)SUS 316L
ISO/TS 15510(2003)X2CrNiMo17-12-2

ASTM 316L Stainless Steel Round Bar UNS S31603 Forged X2CrNiMo17-12-2/1.4404 VOD ASTM A959-2004


FAQ


Q: How do you control the quality?


A: We have professional inspectors to analyze the chemical composition of raw ASTM 316L Stainless Steel Round Bar S31603 Round Bar X2CrNiMo17-12-2 1.4404 Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
