Brand Name: | EA ENERGY |
Model Number: | 18650 |
Certification: | CE MSDS UN38.3 |
Place of Origin: | CHINA |
MOQ: | 1PCS |
Price: | Negotiable |
Payment Terms: | T/T, Western Union, MoneyGram, T/T, D/P |
Supply Ability: | 100000pcs Per Day |
Delivery Time: | 1-5 Work days |
Packaging Details: | 18*18*13cm 200pcs / carton GW:3kg |
Model: | 18650 LFP battery cell |
Capacity: | 1500mAh 4.8Wh |
Cycle life: | >2000 cycles |
Impedance: | <15mΩ |
Diameter: | 18±0.2mm*65±0.2mm |
Voltage: | 3.2V |
Cell type: | LiFePO4 Battery |
Standard discharge current: | Constant Current 0.2C |
Certifications: | CE /UL/UN38.3/ MSDS |
Standard charge current: | Constant Current 0.2C |
Company Info. |
Earlisten Electronic Co,.Ltd |
View Contact Details |
Product List |
18650 Lithium Iron Phosphate LiFePO4 Battery Cells Long Cycle Life
3.2v 1500mAh 18650 LiFePO4 Battery Cell Lithium Iron Phosphate Rechargeable Battery
Quick details:
1. Diameter*Height : 18mm * 65mm (LiFePO4 18650 size)
2. Nominal Voltage : 3.2V
3. Nominal Capacity : 1500 mAh 4.8Wh
4. Cycle life : 2000 cycles
5. Standard charging ways : CC / CV
6. Li-ion / Lithium Ion LiFePO4 battery cell
7. CE , UL , UN38.3 , MSDS compliant
Description:
18650 batteries have a wide range of applications , and lithium iron phosphate batteries have more advantages than ordinary lithium batteries, especially in deep cycle , small current , longer use time products
EA Energy LiFePO4 battery use Automotive Grade LiFePO4 Cells with higher energy density, more stable performance and greater power. Highest-level safety based on UL Testing Certificate for the cell inside.
EA Energy-3.2V-1500mAh-LFP 18650 Battery is a lithium battery cell developed independently for energy storage/ electric vehicle market , which has the characteristics of multifunction, low power consumption, high reliability and high cost performance.
We can customize 12V/24V/36v/48v/60V/72v 20AH, 50AH,100h, 120ah, 150ah,200ah, 300ah, 400ah, 800ah lithium batteries. We can also customize any size and function you need.
Specifications:
NO | Items | Specification | Remarks | |
1 | Nominal Capacity | 1500mAh | 0.2C Discharge | |
0.2C Discharge | ||||
2 | Nominal Voltage/shipping voltage | 3.2V/3.15-3.25V | Voltage | |
3 | Discharge Cut-off Voltage | 2.0V | 0.2C Discharge | |
0.2C Discharge | ||||
4 | Charge Limited Voltage | 3.25±0.03V | 0℃~45℃ | |
5 | Standard Charge Current | 0.2C | 0℃~45℃ | |
6 | Standard Discharge Current | 0.2C | -20℃~ +60℃ | |
7 | Rapid Charge Current | 0.5C | 10℃~45℃ | |
8 | Rapid Discharge Current | 0.5C | -20℃~ +60℃ | |
9 | Max. Charge Current | 1C 1500mAh | ||
Max Pulse Current | 3C | |||
10 | Internal Impedance | ≤40mΩ | AC 1kHz condition | |
At AC 1kHz | ||||
11 | Weight | About 60.0g | Weight 60±2g | |
12 | Storage Temperature Range | ≤1 month | -20~ 45℃ | Factory Voltage 3.2~3.25V |
≤3 months | 0℃~ +30℃ | Ex-factory Voltage3.2~3.25V | ||
≤12 months | 20±5℃ |
Products Details :
Other LiFePO4 battery cells :
Applications:
EA Energy LiFePO4 battery use Automotive Grade LiFePO4 Cells with higher energy density, more stable performance and greater power. Highest-level safety based on UL Testing Certificate for the cell inside. Perfect for solar home, RV, campers, solar, motor homes, off-grid applications
![]() |
