| Categories | Vibration Testing Machine |
|---|---|
| Brand Name: | GSKA |
| Model Number: | Vibration Testing Machine |
| Certification: | CE SGS ROHS UL CE |
| Place of Origin: | Dongguan China |
| MOQ: | Negotiate |
| Price: | Negotiate |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Set / Sets per Month |
| Delivery Time: | 10-60days after confirmed payment or by contract stipulation |
| Packaging Details: | Export package |
| Direction of Vibration: | Horizontal or Vertical |
| Power Source: | AC380V |
| Cooling Method: | Air Cooling |
| Material: | Metal |
| Load Way: | Electronic Load |
| Control: | Computer Control |
Low Frequency Transport Vibration Test Equipment Horizontal / Vertical
Features:
Large loading capacity, the maximum displacement can be reached at
51MMP-P, low working frequency (2HZ)
It can meet the requirements of the sinusoidal vibration test
method (fixed frequency or swept frequency) for the basic test of
international transport packages.
The table body is guided by hydraulic wheels and linear bearings
with low axial rigidity
Air spring support, large load capacity, good low frequency
characteristics, high stability
| Technical indications/Size | GSKA | GSKA | GSKA | GSKA | GSKA | GSKA | GSKA- | GSKA- | |
| major indications of system | Maximum sinusoidal excitation force (N) | 1470 | 1960 | 2940 | 2940 | 5880 | 5880 | 9800 | 9800 |
| Rated frequency range (Hz) | 2-2500 | 2-2500 | 2-2500 | 2-2500 | 2-2500 | 2-2500 | 2-2500 | 2-2500 | |
| Rated unloaded acceleration (M/S2) | 184 | 245 | 367 | 346 | 490 | 490 | 1020 | 1020 | |
| Rated speed (M/S) | 0.8 | 1.2 | 1.1 | 1.2 | 1.1 | 1.45 | 1.4 | 1.8 | |
| Rated displacement (mmp-p) | 40 | 40 | 40 | 40 | 51 | 51 | 51 | 51 | |
| Maximum loading test (KGS) | 140 | 140 | 140 | 140 | 300 | 300 | 140 | 140 | |
| Power consumption (KVA) | 5 | 6 | 7 | 8 | 11 | 14 | 18.5 | 20.5 | |
| Voltage (V) | 380V±10% AC50Hz | ||||||||
| Vibration bench | model | GSKA-200 | GSKA-200 | GSKA-300 | GSKA-300 | GSKA-600 | GSKA-600 | GSKA-1000 | GSKA-1000 |
| Mass of moving part(kg) | 8 | 8 | 8 | 8 | 12 | 12 | 9.5 | 9.5 | |
| Bench size(mm) | Φ230 | Φ230 | Φ230 | Φ230 | Φ230 | Φ230 | Φ200 | Φ200 | |
| Bench weight(kg) | 720 | 720 | 720 | 720 | 1050 | 1050 | 950 | 950 | |
| Bench body size(L*W*H)(mm) | 785*495 | 785*495 | 785*495 | 785*495 | 910*740 | 910*740 | 910*620 | 910*620 | |
| Power amplifier | Model | GSKA-1 | GSKA-2 | GSKA-2 | GSKA-3 | GSKA-3 | GSKA-5 | GSKA8 | GSKA-10 |
| Maximum output power(KVA) | 1 | 2 | 2 | 3 | 3 | 5 | 8 | 10 | |
| Power amplifier weight(kg) | 210 | 210 | 210 | 230 | 230 | 280 | 320 | 340 | |
| Power amplifier size(L*W*H)(mm) | 545*720 | 545*720 | 545*720* | 545*720* | 545*720* | 545*720* | 545*720* | 545*720* | |
| Vibration controller(optional) | GSKA-2A GSKA-3A GSKA-2B GSKA-3A | ||||||||
| Type of cooling | Air cooling | ||||||||
| Executive standard | GB/T13310-1991,GB2423.10-1995,JJG190-1997,IEO68-2-8,company standard Q/320502SN001-2002 | ||||||||
| Remark | Power amplifier-DA type is liner power amplifier,KA is switching power amplifier.controller-SDVC series is sinusoidal vibration control;RDVC series is random control | ||||||||
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
|
