Automotive EMC Test Chamber Electric Vehicle ESA Electro Magnetic Compatibility

EMC Test Solution for Automotive ESA Electric Vehicle Testing Equipment

Complied Standards & Clauses

UN ECE R10 "Uniform Provisions Concerning the Approval of Vehicles with Regard to Electromagnetic Compatibility"

EN 55025/CISPR 25 "Vehicles, boats and internal combustion engines- Radio disturbance characteristics- Limits and methods of measurement for the protection of on-board receivers"
CISPR 12 "Vehicles, boats and internal combustion engines - Radio disturbance characteristics - Limits and methods of measurement for the protection of off-board receivers"
ISO 11452 "Road vehicles-Component test methods for electrical dusturbances from narrowband radiated electromagnetic energy"
ISO 10605 "Road vehicles — Test methods for electrical disturbances from electrostatic discharge"
SAE J1113 "Electromagentic Compatibility Measurement Procedure and Limits for Vehicle Components (Except Aircraft) (60Hz to 18GHz)"
EN 50498 "Electromagnetic compatibility (EMC)-Product family standard for aftermarket electronic equipment in vehicles"

EN301489-1: "ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements"
EN55032: " Electromagnetic compatibility of multimedia equipment - Emission requirements"
IEC 61000-3-2: "Electromagnetic compatibility limits for harmonic current emissions (equipment input current ≤16A)"
IEC 61000-3-3: "Electromagnetic compatibility limits the voltage variation produced with rated current ≤16A and unconditional access of the device in public low-voltage power supply system, voltage fluctuations and flicker limits"

......

System Overview

The whole test system includes EMI test project and EMS test project shown as following:

• EMI test project

The system consists of an SAC, a control room and an amplifier room:
