| Categories | Precision Steel Tube |
|---|---|
| Brand Name: | TORICH |
| Model Number: | TP304 TP304L TP201 TP310S TP316 TP316L |
| Certification: | CE,ISO |
| Place of Origin: | Zhejiang China |
| MOQ: | 3 tons |
| Price: | USD 3-3.5 per ton |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 60000 Tons Per year |
| Delivery Time: | 45-60 days |
| Packaging Details: | in bundles with seaworthy packing |
| Product name: | ASTM A213 Seamless Feritic Austenitic Superheater, Heat Exhchanger Tubes |
| Keyword: | SA213 Heat Exchanger Tubes |
| Usage: | Boiler and Superheater |
| Material: | TP304 TP304L TP201 TP310S TP316 TP316L |
| OO.: | 3.2-127mm |
| Thickness: | 0.4-12.7mm |
| Length: | 6m-12m |
| Shape: | Round Pipe Tube |
| Type: | ASTM A213 Seamless Feritic Austenitic Superheater, Heat Exhchanger Tubes |
| Brand: | TORICH |
| Company Info. |
| TORICH INTERNATIONAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
ASTM A213 Seamless Feritic Austenitic Alloy-Steel Boiler,Superheater, Heat Exhchanger Tubes
Product Discription
| Producsts Name | ASTM A213 Seamless Feritic Austenitic Alloy-Steel Boiler,Superheater, Heat Exhchanger Tubes |
| Technical Standard | TP304 TP304L TP201 TP310S TP316 TP316L |
| Size Range | OD: 3.2-127mm WT: 0.4-12.7mm Length: 6m-12m Cutting Length: according to customers PO. |
| Surface Treatment/Surface Condition | Pickling,Polishing |
| Tube Inspection | Tensile Requirement Hardness Requirement Flattening Test Flaring Test |
Chemical Composition
Material | C | Mn | P | S | Si |
| TP304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 |
| TP316 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 |
| TP304L | 0.035 | 2.00 | 0.045 | 0.030 | 1.00 |
| TP316L | 0.035 | 2.00 | 0.045 | 0.030 | 1.00 |
| TP201 | 0.15 | 5.5--7.5 | 0.060 | 0.030 | 1.00 |
| TP310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 |
| Stainless Steel Mechanical Properties | ||||||
| Grade | Tensile Strength | Yide Strength | Elogation | Hardness | Solution | |
| Annealing | ||||||
| kgf/mm²(N/mm²) | kgf/mm²(N/mm²) | % | HRB(HV) | ºC | ||
| ASTM | TP 304 | ≥53 (515) | ≥21 (205) | ≥35 | ≤90 (200) | 1040ºC-1150ºC |
| TP 304L | ≥50 (485) | ≥17 (170) | Water Quenching | |||
| TP 316 | ≥53 (515) | ≥21 (205) | ||||
| TP 316L | ≥50 (485) | ≥17 (170) | ||||
| JIS | SUS 304 | ≥53 (520) | ≥21 (205) | 1010ºC-1150ºC | ||
| SUS 304L | ≥49 (480) | ≥18 (175) | Water Quenching | |||
| SUS 316 | ≥53 (520) | ≥21 (205) | ||||
| SUS 316L | ≥49 (480) | ≥18 (175) | ||||
| GB | 06Cr19Ni10 | ≥53 (520) | ≥21 (210) | 1010ºC-1150ºC | ||
| 022Cr19Ni10 | ≥49 (480) | ≥18 (180) | Water Quenching | |||
| 06Cr17Ni12Mo2 | ≥53 (520) | ≥21 (210) | ||||
| 022Cr17Ni12Mo2 | ≥59 (480) | ≥18 (180) | ||||
| EN | 1.4301 | (500-700) | ≥20 (195) | ≥40 | 1000ºC-1100ºC | |
| 1.4307 | (470-670) | ≥18 (180) | Water Quenching | |||
| 1.4401 | (510-710) | ≥21 (205) | 1020ºC-1120ºC | |||
| 1.4404 | (490-690) | ≥19 (195) | Water Quenching | |||
Surface Condition
Ferritic Alloy cold-finished steel tubes are free of scale and
suitable for inspection
Ferritic alloy hot-finished steel tubes are free of loose scale and
suitbale for inspection.
Prodution Discription
Prodution Process
Production Workshop
Our Certificate
Company Introduction
FCA
1. who are we?
TORICH is not only professional manufacturer and exporter, but also
international marketing and sales company in the field of steel
tubes from China. Our factory was established in 1997, with the
name of Haiyan Sanxin Steel Pipe Co., Ltd. Our technicians are
equipped with great engineering experience in steel pipe industry
for more than 22 years, they have great command of production
technology for Cold Drawing and Cold Rolling, as well as heat
treatment and inspection. So we have a strong technician team and
manufacturing capability.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Stainless Steel/Carbon Steel/AlloySteel,Titanium,Copper/Brass,etc.
4. what services can we provide?
Accepted Delivery Terms:
FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express
Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit
Card,PayPal,Western Union,Cash,Escrow;
Language
Spoken:English,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
|
