Big Screen Multi Parameter Patient Monitor

Portable VET 12.1-inch big screen Pm-9000a + multi-parameter monitor

Details:

1. The world famous brand module, high precision, standard parameters, reliable quality, stable performance.

2. High brightness high resolution 12.1 inch color TFT LCD display.

3. The body is light and strong, easy to carry.

4. Rotary shuttle operation mode, Bilingual operation interface, easy to learn, easy to use, easy to operate.

5. Ecg display with full lead and seven channels synchronously.

6.ST segment automatic detection, arrhythmia analysis, drug concentration drop table analysis.

7.NIBP double overpressure protection temperature drift control and other technologies to ensure accurate measurement and protect patient safety.

8. Powerful storage capacity, full parameter trend chart chart data, ECG waveform storage and playback, power failure to save data function.

9. The upper and lower limits of alarm can be set arbitrarily, automatic sound and light double alarm.

10. Suitable for cats, dogs and other mammals.

11. Anti-defibrillation, anti-interference of high frequency electroknife.

12. Support wired and wireless networking, support online software upgrade.

13. Optional built-in removable lithium battery, alternating current, dc dual use.

14. Optional built-in dual-channel hot array recorder, real-time printing waveform and icon.

15. It is widely used in all kinds of pet clinics, pet hospitals, veterinary stations and zoos.

Standard configuration: PM-9000A+ pet version of a host, an animal electric clip type cable, a set of animal blood pressure cuff, a set of animal oxygen probe, a set of temperature probe, a power line, a ground wire.

Optional: Built-in rechargeable lithium battery, dual channel thermal printer, monitor cart/stand/hanger.

Technical parameters:

ECG ECG

Lead selection: full lead, ⅰ, ⅱ, ⅲ, aVF, aVR, aVL, V1 -- 6 chest lead display

Gain selection: ×1, ×2, ×0.25, ×0.5 four grades

Frequency: 0.5 Hz - 100 Hz

Common mode signal rejection: greater than 70dB

Scanning speed: 12.5mm/s, 25mm/s, 50mm/s three standard files

Accuracy of heart rate: ±5 beats/min

Calibration signal: 1mV (peak value, accuracy ±3%)

ST segment detection: Measurement range (-2.0mV -- +2.0mV)

Use standard: comply with ANSI/AMI EC13-2002 standard

Response time: 1S

Alarm mode: sound and light alarm

Preset range of heart rate alarm :(alarm over preset value)

The upper limit can be adjusted from 1 to 255 times/min

The lower limit can be adjusted from 0 to 254 times/min

NIBP blood pressure

Technique: oscillographic method

Measurement method: Reverse measurement data is more accurate

Measurement unit: mmHg/Kpa

Overvoltage protection: double safety protection

Measurement time: less than 45S

Cuff pressure range: 0-250mmHg

Accuracy of blood pressure measurement: mean error and standard deviation values specified in ANSI/AAMI SP10-2002

Initial inflation of cuff: 180mmHg (120mmHg for puppies)

Cuff follow-up inflation: original systolic +30mmHg

Blood pressure measurement range and error:

Systolic pressure 60 mmHg to 250 mmHg

The average pressure is 45 mmHg to 235 mmHg

Diastolic pressure 40 mmHg to 220 mmHg

Blood pressure measurement error: ± 1.1kpa (±8mmHg) or ±10% whichever is greater

Response time: 1S

Alarm mode: sound and light alarm

Alarm prediction range and error :(alarm over preset value)

The upper systolic blood pressure ranges from 1mmHg to 255 mmHg

The lower limit ranges from 0 mmHg to 254 mmHg

The upper diastolic blood pressure ranges from 1mmHg to 255 mmHg

The lower limit ranges from 0 mmHg to 254 mmHg

Alarm error: ±1 mmHg

Standard: comply with ANSI/AAMI SP10-2002 standard

SPO2 oxygen saturation

Scope: 0-100%

Accuracy: 1%

Resolution: 1%

Pulse rate: 20-250 beats/min

Response time: 1S

Alarm mode: sound and light alarm

Alarm range and error :(alarm over preset value)

The upper limit is 1% to 100%

The lower limit ranges from 0% to 99%

TEMP temperature

Technology: high sensitivity thermistor probe

Temperature measurement range: 20℃-- 45℃

Resolution: 0.1%

Temperature accuracy: ±1℃

Response time: 1S

Alarm mode: sound and light alarm

Preset alarm range and error :(alarm over preset value)

The upper limit is adjustable between 20.1℃ and 45.5℃

The lower limit can be adjusted between 20℃ and 45.4℃

Alarm error: ±1℃

Breathe RESP

Respiratory rate range: 0-60 breaths/min

Accuracy: + / - 1 RPM

Response time: 1S

Gain selection: ×1, ×2, ×4, ×0.5 four grades

Alarm mode: sound and light alarm

Preset alarm range and error :(alarm over preset value)

The upper limit is adjustable between 10-100 beats/min

The upper limit is adjustable between 0 and 99 beats/min

Alarm error: ±1rpm

Printer (optional)

Specification: Dual channel thermoarray recorder

Printing mode: record waveform and text in real time or triggered by events

Resolution: horizontal: 400dpi/vertical: 800dpi

Note: Date (year/month/day)/Time (24 hours)

Optional wall bracket, mobile bracket, visiting backpack

System

Display: 12.1-inch TFT true color LCD screen

Battery (optional) : LeadAcid fully sealed and maintenance-free battery

Safety standard: LEC601-1 (INTERNATIONAL GB9706.1)
