Dn50 Random Tower Packing Raschig Rings SS304 For Chemical Industry

Categories Metal Pall Ring
Brand Name: Yuanqiao
Model Number: Pall ring
Certification: ISO9001
Place of Origin: Anping, China
MOQ: 1pc
Price: Negociation
Payment Terms: L/C, T/T
Supply Ability: 1000 pcs per month
Delivery Time: 5-10 days
Packaging Details: Wooden boxes
Product Name: Metal Pall Ring
Material: Stainless Steel 304, 316L, Etc.
Shape: Hollow columns
Size: 16mm 25mm 38mm 50mm 76mm
Application: Tower packing media
Type: Ring
Keyword: metal pall ring
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Dn50 Random Tower Packing Raschig Rings SS304 For Chemical Industry

Dn50 Tower Random Ss304 Packing Pall Ring For Chemical Industry


Dn50 Tower Random Ss304 Packing Pall Ring For Chemical Industry

Description
Items:Metal Pall RingMaterial:SS304, SS316L SS316, Other
Size:9mm-76mm ETCWall Thickness:0.3-1.2mm
Model Number:HL20211012-02Usage:Absorption ,Chemical Engineering ETC
Material Certificate:YesData Sheet:Available
OEM:YesEqual Inch Type:1in, 2in, 3in, 3/8in, 5/8in, 1 1/2inch Other
High Light:

ss304 packing pall ring

,

dn50 packing pall ring

,

chemical industry 50 mm pall ring

SS304 DN50 Tower Random Packing For Chemical Industry Metal Pall Ring

Product Introduction


1. The pall ring is an improvement of the raschig ring.
2. The difference for the Pall Ring is the addition of two rows of punched and formed fingers.
3. This adjustment provides a significant performance increase: the capacity and efficiency is improved and the pressure drop is reduced.

Technical Data of metal pall rings:

Nominal size16 mm pall ring
Thickness0,3 mm
Weight340 kg/m³
Surface area360 m²/m³
Void fraction95 %
Materialstainless steel
Available materialscarbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request

Nominal size25 mm pall ring
Thickness0,5 mm
Weight393 kg/m³
Surface area215 m²/m³
Void fraction95 %
Materialstainless steel
Available materialscarbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request

Nominal size38 mm pall ring
Thickness0,5 mm
Weight285 kg/m³
Surface area145 m²/m³
Void fraction96 %
Materialstainless steel
Available materialscarbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request

Nominal size50 mm pall ring
Thickness0,5 mm
Weight207 kg/m³
Surface area112 m²/m³
Void fraction97 %
Materialstainless steel
Available materialscarbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request

Nominal size76 mm pall ring
Thickness0,7 mm
Weight109 kg/m³
Surface area78 m²/m³
Void fraction98 %
Materialstainless steel
Available materialscarbon steel, titanium, hastelloy, nickel, copper, aluminium and others on request

Material


Metal Pall Ring, Stainless steel Pall rings, Packing Pall Ring are available in a wide range of materials such as stainless steel ,carbon steel ,aluminum, bronze,304L,316L,and other alloy etc.


Applications of metal pall rings

1Degassing
2Gas washing
3Steam stripping
4Air pollution control scrubbers
5H2S, NH3 & SO2 absorption and stripping
