Brand Name: | JBHD |
Model Number: | 5083 Aluminum Sheet |
Certification: | ISO9001,SGS,ISO |
Place of Origin: | CHINA |
MOQ: | 1 ton |
Price: | Negotiable |
Payment Terms: | T/T, Western Union, L/C, MoneyGram |
Supply Ability: | 10000 Tons per Month |
Delivery Time: | 7-15 work days |
Packaging Details: | Standard seaworthy export packing or as customer demands |
Material: | Aluminum Material,1050/1060/1070/1100/3003/5052/5083/6061/6063 |
Standard: | ASTM AISI JIS DIN GB |
Temper: | O-H112,T351-T851,T3-T8,O-H112/T3-T8/T351-T851 |
Alloy Or Not: | Is Alloy |
Thickness: | 0.1mm~200mm |
Width: | 100mm~2000mm |
Application: | Decoration,Construction,roofing,Building,industry Traffic Aircraft |
The Most Promising Aluminum Sheets---5083 Aluminum Plate
1. The Extend Market Demands
The inevitable one that come into my mind when it comes to why 5083
aluminum plate are the most promising aluminum sheets is the extend
market demands. Realize it or not, 5083 aluminum plate are widely
used in aerospace, transportation, electrics and so on. For
example, you can see the shadow of 5083 aluminum plate in aircraft
fuel tank, cars, boats and so on. And as far as the auto aluminum
field is concerned, 5083 aluminum plate have a broad market
prospect.
2. The Advantageous Performances of 5083 aluminum plate
If the extend market demands of 5083 aluminum plate is the
foundation of 5083 aluminum sheets becoming the most promising
aluminum sheets, then it is the advantageous performances of 5083
aluminum sheets that makes 5083 aluminum sheets apply to so many
fields. The good corrosion resistance and weld-ability and cold
workability and its medium strength are closely related to its
widely used fields. All of this makes 5083 aluminum sheets warmed
welcome by insiders.
Alloy | Temper | Thickness mm | Tensile Strength Rm/Mpa Min. | Yield Strength Rp0.2/Mpa Min. | Elongation % Min. |
---|---|---|---|---|---|
5083 | O / H111 | 6-12.5 | 275-350 | 125 | 16 |
12.5-50 | 275-350 | 125 | 15 | ||
>50 | 270-345 | 115 | 14 | ||
H112 | 6-12.5 | 275 | 125 | 12 | |
12.5-40 | 275 | 125 | 10 | ||
>40 | 270 | 115 | 10 |
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | Other | Al | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Each | Total | ||||||||||||
5083 | 0.40 | 0.40 | 0.10 | 0.40 -1.0 | 4.0 -4.9 | 0.05 -0.25 | – | 0.25 | 0.15 | – | 0.05 | 0.15 | Remainder |
Due to its strength and temperature characteristics, 5083 aluminum plate is used in aircraft fuel tanks, pipelines, and transportation vehicles, ship sheet metal parts, instruments, lights bracket and rivets, metal products, electrical appliances, such as Shell.
FAQ:
Q1: What's your terms of payment?
A: 30%T/T as the upfront deposit, 70% before delivery, We will show
you the photos and package before you pay the balance.
Q2: What's the terms of delivery?
A: EXW, FOB, CFR, CIF
Q3: What's your delivery time?
A: For stocks, we could transport the goods to loading port within
15 work days after we received the deposit.For productionperiod, it
usually takes about 15 days to 30 days after we received the
deposit.
Q4: Could you produce according to the samples?
A: Yes, we can customer-made by your samples or technique drawings.
Q5: Could youprovide the compliment samples?
A: Yes, we could provide the free samples on condition that it is
available in stocks, however,the transportation fee is borne by
buyer.
![]() |
