| Categories | Container Cold Room |
|---|---|
| Place of Origin: | Hunan, China |
| Brand Name: | icemedal |
| Certification: | CE |
| Packaging Details: | Standard wooden case. |
| Supply Ability: | 30 Set/Sets per Month |
| Price: | $6,000.00/sets >=1 sets |
| Model Number: | VCR |
| MOQ: | 1 Set |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time: | ≤1 Set 35 Days |
| Applicable Industries: | Hotels, Garment Shops, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Food & Beverage Shops, Other |
| Temperature: | -40℃ ~ +20℃ |
| Power: | 380V or 220V, Single phase , 50Hz or 60Hz, Depends on cold room size and temperature |
| Weight: | 1000 KG |
| Panel Thickness: | 100mm, 120mm, 150mm, Other |
| Cooling way: | Water cooling or air cooling |
| Key Selling Points: | Easy to Operate, High-accuracy |
| Dimension(L*W*H): | customized |
Icemedal Mobile Cool Room Movable Portable Cold Storage For Block Ice In Nigeria
Panels thickness (mm) | Temperature gap between internal- external environment | Height of wall panel (max) | Roof length (max) | Applicable temperature for cold room (℃) |
mm | ℃ | m | m | 25 20 15 10 5 0 -5 -10 -15 -20 -25 -30 -40 -45 -50 -55 |
50 | 30 | 3.5 | .4 | |
75 | 40 | 4.5 | 3.8 | |
100 | 50 | 5 | 4.5 | |
120 | 60 | 5.5 | 6 | |
150 | 70 | 6 | 6.5 | |
200 | 90 | 7 | 7.6 |
Evaporator:
The plate-and-tube evaporator has aluminum plate-and-tube and steel
plate-and-tube, among which the cold room aluminum plate-and-tube
has many advantages such as high heat transfer coefficient, light
weight, no rusting, long service life and easy installation.
Chiller:
Mainly composed of cooling heat exchange exhaust pipe, axial fan,
liquid distributor, frost melting device, and Receiving water tray
and other 5 important components. The most common ways of melting
frost. Electric frost melting, water flushing frost.
|
