Sj120x25 Pvc Plc Wire Extrusion Machine Electric High Speed

Categories Cable Extrusion Machine
Brand Name: Beyde
Model Number: SJ120
Place of Origin: China
MOQ: 1 set
Payment Terms: L/C, D/A, D/P, T/T
Usage: Extruding
Voltage: 380V 50hz
Application: Wire Processing
Color: According to customer requirement
Name: electrical wire and cable making machine,Cable Making Equipment,Outer cable extrusion machine
Line speed: 150-180m/min
Speed: max.180m/min
Product name: Cable extrusion machine
Warranty: 1 Year
Extruding material: LSZH
Company Info.
Beyde Trading Co.,Ltd
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Sj120x25 Pvc Plc Wire Extrusion Machine Electric High Speed

SJ120X25 Cable Extrusion Line High Speed Pvc Electric Cable Extrusion Machine


1.Main features of machine

This equipment is applicable to outer surface extrusion of wires and cables for insulation materials such as PVC,PE,LSZH,etc.


2. Technical Characteristics
1. Inlet Wire Diameter:
2. Finished Wire Diameter: Φ10 mm~Φ70mm
2. Applicable Material: PVC
3. Screw Diameter: Screw Diameter 120mm
4. Extrusion Capacity:max480 kg/h
5. Linear Velocity: 5~150m/min
6. Length of Production Line: 38Meters
7. Installed Capacity: About 155KWh
8. Color: customerized

3. Parameter:

ItemNameModelQuantity
1Side-axis Pay-off Frame1250-1500mm1 set
2Cover-type Tractor800kg1 set
3Straighter5 wheels1 set
4Extruder+cross head+PVC feeder120mm1 set
5Electrical Control BoxPLC1 set
6Ink printing machine1 set
7Water Cooling Tank20 meters1 set
8Drying Machine1 set
9Spark testing machine1 set
10Meter counting stand1 set
11Cover-type Tractor1600KG1 set
12Side-axis Taking-up and Traversing Machine1200-2500 mm1 set
13Spare partssome

4. 120mm Extruder with cross head

Applicable Material: PVC, Plasticization degree of 100%.

Maximum Extrusion Capacity:260kg/hr.

Mechanical Center Height: 1000mm

Ratio of Length and Diameter: 1:25

Compression Ratio: 1:2.8

Rotation Rate of Screw: 0—60 RPM

Material of Screw: One Ø120mm screw with whole tooth nitrogen

treatment of alloy steel and chrome-plated polished surface and screw-passing cooling water device.

Material of Screw Cylinder: 38CrMoA1A alloy steel, nitrogen treatment and precisely grinding. The surface hardness inside the screw cylinder is R2-3 degree higher than that of the front surface of the screw and the screw thread. The cooling water jacket is added on the feed point of the screw cylinder.

Gearbox: Imitation of Italian-type, hardened helical gear gearbox, material of cast steel, oil-bath lubrication, tooth-face high-efficiency quenching and adoption of Japanese NACHI bearing.

Electric Heating: 380V, with even three-phase separated flow.

Screw cylinder electric heating zone 6, the cast aluminum heating ring heating is affixed with cooling air duct.

Head electric heating zone 1, heating by cast aluminum heating ring.

Neck electric zone 1, heating by the electro-thermal tablets.

Eye die electric heating zone 1, heating by the electro-thermal tablets.

Control of Temperature: Use the PID automatic temperature control gauge made in Yangming, Taiwan, automatically set the control under 0-399℃ and use KTYP as the thermal-couple.

Cooling: Screw cylinder zone 6, use 6 sets of cooling fans (550W).

Head: Right-angle adjustable eccentric head.

Host Motor: The motor drags with 90 KW. The inverter controls and unloads by synchronization. The velocity adjustment is convenient and steadily operated.
