| Categories | Steel Forging Parts |
|---|---|
| Brand Name: | PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL |
| Model Number: | Custom 455, AMS 5617 |
| Certification: | SGS,TUV,BV,ISO,MTC |
| Place of Origin: | China |
| MOQ: | Negotiations |
| Price: | Negotiations |
| Payment Terms: | T/T |
| Supply Ability: | 55000KGS/Month |
| Delivery Time: | Ex-stock for delivery: 3-7 days Production lead time: 30-60 days |
| Packaging Details: | Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement |
| Product name: | Custom 455 Steel Forging Parts |
| Grades: | Custom 455, AMS 5617 |
| Processing methods: | Milled, Cold working, Machined, etc. |
| Heat treatment condition: | Solution Treated, Quenched And Tempered,etc |
| Surface: | Grinding, Centreless Ground, etc |
| Available Shapes: | Flat bar, Length, Heavy, middle plate via hot rolled, Sheet steel via cold rolled, Steel strip via cold rolled, Forging piece,etc |
| Price Term: | Ex-work, FOB, CIF, CFR, DDU etc. |
Custom 455 Steel Forging Parts AMS 5617 Flat Bar
Description
Custom 455 Steel Forging Parts AMS 5617 Flat Bar is an advanced
martensitic alloy in the area of precipitation hardening stainless
steels. Custom 455 Steel Forging Parts AMS 5617 Flat Bar combines
corrosion resistance, one-step age hardenability, ease of
fabrication.
All of Custom 455 Steel Forging Parts AMS 5617 Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
Custom 455 Steel Forging Parts AMS 5617 Flat Bar
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
C (％): ≤ 0.030 Si (％): ≤ 0.50 Mn (％): ≤ 0.50 P (％) ≤: 0.015 S (％) ≤: 0.015 Cr (％): 11.00 ~ 12.50 Ni (％): 7.50 ~ 9.50 Ti (％): 0.90 ~ 1.40 Mo (%): ≤ 0.50 Cu (%): 1.50 ~ 2.50 Nb (%): ≤ 0.50 N (%): ≤ 0.015 | Form: bar, plate, strip, sheet and forgings Tensile strength, σb/MPa: 793 max. ( wire , cold drawn, annealed ) Heat treatment condition: Tensile strength, σb/MPa: 1500 min. Yield strength, σ0.2/MPa: 1413 min. Elongation, δ(％): 10.0% min. Reduction of area, ф (％): 40.0% Hardness under annealed condition | HBW: 331 max. |
Applications:
Custom 455 Steel Forging Parts AMS 5617 Flat Bar is often used in
the Drill bits, Drivers, Distractors, Shafts, Surgical instruments
for orthopedic, spinal, and dental markets, etc.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
|
