Home > Arc Welders >

MMA-400F 280 AMP Arc MMA Welder Machine Lightweight Low Power Consumption

Categories Arc MMA Welder
Brand Name: JONE
Model Number: MMA-400F 500F 630F
Certification: ISO9001,CE,CCC
Place of Origin: China
MOQ: 10PCS
Price: Negotiate
Payment Terms: L/C, T/T, Western Union,, D/A, D/P
Supply Ability: 3 thousand pieces per year
Delivery Time: 30days
Packaging Details: 540*295*425 kraft paper box+ foam
Type: IGBT MODULE
AC Input Voltage(V): 380V
Real Amp(A): 280A/380A/530A
Rated Input Power Capacity(KVA): 15
Non-load Voltage(V): 77
N.W./G.W.(kg): 10.3/12.3
Quick joint Size(mm): 35-50
Protection class of case: IP21
Electrode diameter (mm): 1.6-5.0
Package(LxWxH mm): 540*295*425kraft paper box+ foam
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

MMA-400F 280 AMP Arc MMA Welder Machine Lightweight Low Power Consumption

MMA/ARC 400F amps IGBT Inverter easy-using Stick arc welding machines arc welder

Description

  • The inverter arc welding machine is a powerful and versatile tool for any welding project. It features energy saving, multiple functions, portability and user friendly. The inverter arc welding machine adopt the most advanced inverter technology, that guarantees superior welding performance, nice welding result and minimum post-welding treatment.

Features

  • inverter IGBT technology

  • Lightweight, small volume, move conveniently

  • Arc self-adjustable

​​MMA inverter welder characteristics

  • It features advanced IGBT inverter technology and has low power consumption, so it'll run just as well on small jobs as it will on large ones. It also features high no load voltage, which means no spatter when you're welding and no need for additional shielding.
  • The machine can be used with acid and alkaline electrodes, so you'll never have to worry about the type of electrode you use!
ModelMMA-400FMMA-500FMMA-630F
TypeIGBT MODULEIGBT MODULEIGBT MODULE
Real Amp(A)280380530
AC Input Voltage(V)380V380V380V
Rated Input Power Capacity(KVA)151515
Input Frequency(Hz)50/6050/6050/60
Non-load Voltage(V)777777
Output current range(A)20-40020-50020-630
Rated Duty Cycle(%)60%60%60%
Efficiency(%)85%85%85%
Class of InsulationFFF
Protection class of caseIP21IP21IP21
Electrode diameter (mm)1.6-5.01.6-5.01.6-5.0
Quick joint Size(mm)35-5035-50 plate quick joint35-50 plate quick joint
Input power cable(m)1.81.81.8
N.W./G.W.(kg)9.3/12.310.3/12.313.5/15.5
Machine Size(LxWxH mm)480*215*380480*215*380480*215*380
Package(LxWxH mm)540*295*425 kraft paper box+ foam540*295*425 kraft paper box+ foam540*295*425 kraft paper box+ foam
Accessories2M 35m2 300A holder2M 50m2 500A holder2M 50m2 500A holder
2M 35m2 300A Clamp2M 35m2 300A Clamp2M 35m2 300A Clamp
Brush,Mask,ManualBrush,Mask,ManualBrush,Mask,Manual

Advantages Of Electric Welding Machine

  • The welding machine is for welding the base metal of a single type to another one, with high precision and strong welds. Electric is suitable for working in dry environment, does not need too many requirements, because the volume is small, the operation is simple, the use is convenient, it uses electricity generated by the electric welding machine to heat iron wire or electrodes, which causes a current to flow through the wires or electrodes and melt the iron wire or electrode into molten iron. Welding can be done in different positions. Electric welding machine has a variety of functions such as automatic starter control function after power failure restart function low price and good quality etc.

FAQ

Q: Can I get some samples?
A: Yes,we are glad to offer you samples.After price and order confirmed, the samples fee will be regressed.


Q: When can I get the products?
A: You products will be arrived your the nearest domestic port after order confirmed, it's about 30 days.


Q:Why should I choose your welding machines?
A:This is a question in many buyers mind, we are a quality-based professional welding machines company with great products and service, and we are a skill-oriented company. We believe in smart work and hard work combined. We never lose sight of our customer's requirements. We provide world-class training sessions to our staff and our associates, yes "world class", don't believe us? We cordially welcome you to come and observe one of our sessions.


Q:Delivery

A:The 1000pcs goods need 35-40 days after we receive the deposit.


Cheap MMA-400F  280 AMP Arc MMA Welder Machine Lightweight Low Power Consumption for sale
