Molybdenum Alloy Thermode Auto Hotbar Machine PLC Controlled

PLC Control And Molybdenum Alloy Thermode Auto Hotbar Machine

Auto Hotbar Machine Overview:

Hot press is also called bonding machine. According to the different media of hot pressing, it can be divided into soldering, ACF bonding machine (opposite conductive tape), ACP (opposite conductive glue), TBF (hot melt adhesive film). It is applicable to the connection of FPC (flexible circuit board), HSC (Zebra paper), tab and LCD and PCB. As the pitch of PCB or FPC in consumer electronic products tends to be smaller, the traditional soldering process has been difficult to meet the requirements of extremely fine hot pressing, so the ACF process has been gradually applied by mobile phone designers.

Auto Hotbar Machine Advantages:

1. Very high working efficiency, suitable for high volume production.

2. Max 10mm long thermode head for larger applications.

3. Molybdenum alloy thermode heads have uniform heating and high welding quality.

4. Customized fixtures are available for high quality soldering of different applications.

5. Imported PLC system ensures stable running.

Auto Hotbar Machine Specification:

Auto Hotbar Machine Applications in Mobible Phones Manufacturing:

It is used on the internal parts of mobile phones. Everyone is familiar with touch screen smart phones. Mobile phones are now basically necessary for people, and some people even have more than one mobile phone. You may not know that the mobile phone you use every day will also use the hot bar soldering. Because the hot bar soldering machine sounds like a big machine, you feel that the operation goal is also some huge parts. However, small mobile phones often use the pulse heat bonding. The pulse heat welding machine is usually used for the function module of the mobile phone screen or when the camera FPC is welded to the PCB.

Factory established in 2005, has built and maintained its reputation as a source of technical

and professional excellence.

Winsmart has a driven, experienced, and knowledgeable team, providing extensive array of solutions

for PCB depaneling and soldering. Above all, it takes pride in the quality and efficient service that it

provides to customers, which is reflected by long-standing relationships across a diverse customer base.

Winsmart will continue to meet customers' requirements by supplying the excellent solution with

unique technology and service!
