MSRR 6517 Steel Forging Parts BS S150 Solid Square Bar

Categories	Steel Forging Parts
Brand Name:	PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number:	MSRR 6517 Steel Forging Parts BS S150 Solid Square Bar
Certification:	SGS, TUV, BV, ISO, MTC
Place of Origin:	China
MOQ:	1000kg
Price:	Negotiations
Payment Terms:	T/T
Supply Ability:	50000KGS/Month
Delivery Time:	Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details:	Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Characteristic:	Corrosion Resistant
Heat treatment condition:	+NT, +QT, +AT, etc.
Processing methods:	Milled, Cold working, etc
Available Shapes:	Round bar, Flat bar, Length, Heavy, middle plate via hot rolled, etc
Surface:	Rrough Turned, Polished, Black
Material Category:	Martensitic Stainless Steel

Contact Now

Add to Cart

Company Info.

Mianyang Baoheng New Material Technology Co.,Ltd

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

MSRR 6517 Steel Forging Parts BS S150 Solid Square Bar

MSRR 6517 Steel Forging Parts BS S150 Solid Square Bar

Product Information

BS S150 is a highly metallurgically tested martensitic stainless steel, it has comparable structural strength to low alloy carbon steel but with superior corrosion resistance, it is capable of hardening on air cooling and has high resistance to stress corrosion capability and can be used at high temperatures up to 550°C

Size Range

Round bar / Wire rod (Diameter):

3.0 mm to 1000 mm

Square bar / Flat bar:

3.0 mm to 1000 mm

Forging piece:

Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled:

T3.5 - 100 mm X W5 - 1000 mm X L1000-10000 mm

Sheet steel via cold rolled:

T0.3 - 10.0 mm X W5 - 1000 mm X L1000 - 10000 mm

Steel strip via cold rolled:

T0.3 - 10.0 mm X W5 - 1000 mm X L (or in coil form)

Length:

Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

BS S150/MSRR 6517

BS EN 3890 - 2002

C(％): 0.08~0.16
Si(％): 0.15~0.60
Mn(％): 0.30~1.20
P(％)≤: 0.030
S(％)≤: 0.025
Cr(％): 9.80~11.20
Ni(％): 0.60~1.20
Mo(％): 0.40~0.80

V(%): 0.10~0.25

Nb(%): 0.15~0.45

Mechanical Properties

X2CrMnNiN 17-7-5/1.4371 Alloy Round Bar Mechanical Properties

Tensile strength, Rm/MPa: 930~1130
Yield strength, Rp/MPa: ≥760
Elongation, A/%: ≥14
Reduction of area, ψ/%: --
Impact, AKV /J: --
Annealed hardness HBW: 288~331

Application

S131 stainless steel is used in aerospace, commercial aircraft, gas turbine industry
