305mm Portable Handheld Ultrasound Scanner Probe Convex+Linear+Cardiac

Categories Portable Ultrasound Scanner
Brand Name: BIO
Model Number: W6
Certification: CE
Place of Origin: China
MOQ: 1 unit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100 units / month
Delivery Time: 7 Working days
Packaging Details: Carton (240x235x100mm), 1.1Kgs/carton
Frequency: 3.5/5.0mhz, 7.5/10mhz, 2.5/5.0mhz
Depth: 90-305mm, 20-100mm, 90-160mm
Host: Tablet, Smart phone, PC
Display Mode: B, B/M, color, PW, PDI
Connection: WIFI & USB
Battery lasts: 3-4 hours
Weight: 200g
Application: Handheld Cardiac Probe
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

305mm Portable Handheld Ultrasound Scanner Probe Convex+Linear+Cardiac

Portable Handheld Ultrasound Scanner Convex+Linear+Cardiac Ultrasound Probe Portable Ultrasound Scan Machine


Newest Wireless ultrasound scanner with dual probe, multipurpose handheld convex+linear+cardiac Ultrasound probe can

diagnose whole body parts. It can be used by wired or wireless connection to mobile phones/ipad/PC.

It is IPX7 waterproof, you can scan whole body part anytime anywhere.


Specification


1Product nameWireless Probe
2Elements128
3Frequency3.5/5.0mhz, 7.5/10mhz,2.5/5.0mhz
4Depth90-305mm, 20-100mm, 90-160mm
5HostTablet, Smart phone, PC
6ConnectionWIFI&USB
7Software Adjustable ParametersGN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down.
8Measurement

Length, Area/Circumference, Angle, Trace, Distance GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL), Heart rate, Time, Distance, Velocity, Heart rate(2), S/D, Depth.

9Playback Frames100, 200, 500, 1000 optional
10Image Gray Scale256 level
11Display ModeB, B/M, color, PW, PDI
12Image Savejpg, avi, Mp4 and DICOM format
13WiFi TypeBuilt-in WiFi, 802.11g/20MHz/5G/450Mbps
14Channel64
15Frame24s/f
16Gain40-110Db
17LanguageEnglish, Chinese,Russian, German, Italian, Spanish, Portuguese
18Powerby built-in battery
19Battery ReplaceableYes
20Battery Last3hours (Working time), 12 hours(Stand by time)
21ChargerUSB Charger, wireless charger

Standard Configuration


1Wireless probe1pc
2USB cable1pc
3Power Plug1pc
4Wireless charger1pc
5Wrist strap1pc
6Portable aluminium alloy box1pc
7User's Manual_E format1pc
8Warranty Card_Eformat1pc

Images





Features


1

128 element double head convex + linear + cardiac preset wireless color Doppler ultrasound probe.

2

Only 200g, easy to carry.

3

B, B/M, Color, PW, PDI mode

4

WIFI&USB connection


Service


- After-sale Service

  1. Please provide us with a video to identify the problem.
  2. If you encounter software problems, we will guide you how to solve them, and if necessary, our professional engineers will upgrade the software.
  3. If you encounter hardware problems, it will be repaired free of charge during the warranty period.

- Return Policy


It must be ensured that the product is free of any damage and the product is complete;

secondly, the return shipping and customs clearance costs of the product are borne by the buyer and

refunded after deducting these costs.


-Warranty Policy

We provide an 18-month warranty period. If there is any quality problem during the warranty period,

it needs to be sent to our company's address for free repair.
