Bottom Feed High Speed Slitting Rewinding Machine

Bottom Feed High Speed Slitting Rewinding Machine

Description

This machine is suitable for slitting narrow paper. It has the functions of automatic meter counting, setting length, setting quantity, automatic stop, unwinding controlled by photoelectric automatic correction etc. The whole machine is characterized by compact structure, fast speed, high efficiency, accurate cutting, single operation, stable operation etc.

It is two roll upper feed rewinding machine without axle. The paper jumbo roll which is finish the first step on the paper making machine put on the unreeling stand of rewinding machine to slit into special width, diameter and tighten paper roll. Remove the bad quality paper at the same time.

The slitting rewinding machine working principle: The paper roll which is taken down from reeling machine put on the unreeling stand of rewinding machine. There is pneumatic braking device on the unreeling stand to keep the tension of paper. The paper will be leaded out downward by release paper roll via paper guide roll. Finally reel on the winding paper tube after slitting via slitting system. The winding paper tube is driven by front back-up roller to bring whole paper move on.

Function of the slitting rewinding machine

Main technical parameters

Qinyang PingAn Light Industry Machinery Co., Ltd is one of the member companies of China paper making machinery association. We are a large paper making equipment enterprise integrating technology research & development, design, manufacturing, and marketing services.

Founded in 1985, the company established a large-scale standardized joint-stock enterprise according to the modern enterprise mechanism in 2006, and now has 178 employees, including 24 engineers and technicians, and 8 senior engineers from Xi'an Walmet. Our company is located in Li Village Industrial Zone, Qinyang City, Henan Province, China, covering an area of 6000m², and has 1 R&D department, 8 modern manufacturing workshops, 1 quality inspection center and has more than 50 sets of large and medium-size equipment with a series of functions, such as scientific research, design, production, testing, assembly and commissioning. The company has passed the ISO9001:2000 international quality management system certification and enjoys the right of import and export.

Our company's main product is large size paper making machine. The largest paper machine width we produce reaches 6000mm, working speed of 700m/min. The main production lines include packaging paper production lines with an annual output of 20,000-2,000,000 tons, cultural paper production lines with an annual output of 10,000-100,000 tons, tissue paper production lines with an annual output of less than 20,000 tons and various special paper production lines. Our company serves paper making enterprises, including plant design, production process, overall design, equipment processing, installation and debugging, worker training, after-sales service and so on.

With the principle of honest management, fine management and high quality service, our company has developed rapidly in recent years, and has developed a safe operation mode, which makes all kinds of papermaking equipment put into the market of domestic and abroad and received good comments from our customers.
