Hexagon Brass Copper Pipe Cap 1/4 NPT End Cap UNS 70600

Categories	Copper Pipe Cap
Brand Name:	METAL
Model Number:	Butt Welding Fittings
Certification:	SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin:	China
MOQ:	1pcs
Price:	Depending on quantity
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	3,0000pcs per month
Delivery Time:	20-35 Days
Packaging Details:	Standard export sea-worthy packing
Product Name:	Copper Cap
Material:	UNS 70600
Size:	1"-36"
Thickness:	2.5MM-19MM
Standard:	EEMUA 146 SEC.2
Sample:	Avaliable

Contact Now

Add to Cart

Company Info.

TOBO INDUSTRIAL (SHANGHAI) CO., LTD

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Hexagon Brass Copper Pipe Cap 1/4 NPT End Cap UNS 70600

Copper Fittings Hexagon Brass 1/4 Npt End Cap Brass Pipe Fittings Caps For Copper Pipe

Copper Nickel End Cap

The table here shows copper nickel end caps’ dimensions & sizes according to Europe standards like EEMUA, DIN & Similar. Furthermore it has details for both seamless and seam welded copper nickel end cap variants. It also lists Wall Thickness (WT) and Theoretical Weight for the pipes which can withstand pressure of 10 bar, 14 bar, 16 bar, 20 bar respectively.

At Cunimet Alloy International, we manufacture and export cupronickel end caps strictly following the below mentioned Europe Standards, other international standards or as per the specifications mentioned by the client.

CuNi End Cap - DIN 86088, similar

10 BAR – Material: CuNi10Fe1Mn

OD		WT	HEIGHT		THEORETICAL WEIGHT
Nominal	Actual	e	h1	h4	THEORETICAL WEIGHT
inch	mm	mm	mm	mm	kg/piece

	SEAMLESS
1	30	1,5	14	5	0,07
1 1/4	38	1,5	14	605	0,1
1 1/2	44,5	1,5	14	8	0,12
2	57	1,5	18	10	0,18
2 1/2	76,1	2	18	14	0,31
3	88,9	2	20	16	0,39
4	108	2,5	20	20	0,75
5	133	2,5	20	24	0,95
6	159	2,5	20	29	1,35
7	193,7	2,5	20	36	1,95
8	219,1	3	20	41	2,6
10	267	3	20	50	3,85
12	323,9	4	20	61	6,6
14	368	4	20	69	8,8
16	419,1	4	20	79	12,2
18	457,2	4	20	87	12,55
20	508	4,5	20	96	18,8
24	610	5	20	115	26,7

14 BAR – Material: CuNi10Fe1Mn

OD		WT	HEIGHT		THEORETICAL WEIGHT
Nominal	Actual	e	h1	h4	THEORETICAL WEIGHT
inch	mm	mm	mm	mm	kg/piece

	SEAMLESS
1	30	1,5	14	5	0,07
1 1/4	38	1,5	14	605	0,1
1 1/2	44,5	1,5	14	8	0,12
2	57	1,5	18	10	0,18
2 1/2	76,1	2	18	14	0,31
3	88,9	2,5	20	20	0,75
4	108	2,5	20	20	0,75
5	133	3	20	24	1,2
6	159	3	20	29	1,6
7	193,7	3	20	36	2,4
8	219,1	3,5	20	41	3,1
10	267	4	20	50	4,85
12	323,9	5	20	61	8,2
14	368	5,5	20	69	12,6
16	419,1	6	25	79	17,4
18	457,2	6	25	87	17,9
20	508	6,5	25	96	26,35
24	610	8	35	115	49,5

CuNi End Cap - EEUMA 146 Standards

16 BAR – Material: CuNi10Fe1Mn, CuNi30Fe1Mn

OD		WT	HEIGHT	THEORETICAL WEIGHT
Nominal	Actual	e	h1 + h4	THEORETICAL WEIGHT
inch	mm	mm	mm	kg/piece

	SEAMLESS
1 1/2	44,5	2,5	19,6	0,13
2	57	2,5	22	0,19
2 1/2	76,1	2,5	25,7	0,31
3	88,9	2,5	28,2	0,4
4	108	3	31,7	0,75
6	159	3	41	1,5
8	219,1	4	55	2,75
10	267	4,5	69	4,9
12	323,9	5,5	80	9,17
14	368	6,5	93	14,05
16	419,1	7	102	18,6
18	457,2	8	119	22,75
20	508	8,5	129	31,7
24	610	10,5	148	56,16
28	711	12	176	85,55
32	813	13,5	200	125,4
36	914	15,5	221	175,4

20 BAR – Material: CuNi10Fe1Mn, CuNi30Fe1Mn

OD		WT	HEIGHT	THEORETICAL WEIGHT
Nominal	Actual	e	h1 + h4	THEORETICAL WEIGHT
inch	mm	mm	mm	kg/piece

	SEAMLESS
1 1/2	44,5	2,5	19,6	0,13
2	57	2,5	22	0,19
2 1/2	76,1	2,5	25,7	0,31
3	88,9	2,5	28,2	0,4
4	108	3	31,7	0,75
6	159	3,5	44	17,75
8	219,1	4,5	60	3,1
10	267	5,5	69	5,96
12	323,9	7	85	11,68
14	368	8	103	17,3
16	419,1	9	112	23,9
18	457,2	9,5	119	27
20	508	11	139	41
24	610	13	163	68,3
28	711	15	191	106,9
32	813	17	210	157,9
36	914	19	231	215
