| Categories | Stainless Steel Pipe |
|---|---|
| Brand Name: | DELTA |
| Model Number: | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 500 kgs |
| Price: | 2000-3000 USD/Ton |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 10 Ton per week |
| Delivery Time: | 5 - 12 days based on the quantity |
| Packaging Details: | standard packing for export |
| Products: | stainless steel seamless pipe |
| Grade: | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
| Standard: | ASTM GB EN |
| Length: | 6m or custom cutting any length as request |
| Diameter: | DN10 - DN400 |
| Wall thickness: | SCH10 - XXS or unstandard size |
| Type: | seamless pipe |
| Service: | cutting, polishing |
| Similar Grade: | 410 420 17-4ph |
| Packing: | wooden box or PP bag |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
410S Stainless Steel Pipes Seamless Pipe / Welded Pipe DN20 - DN200 for Ship Structure
410 Stainless Seamless Pipe is a basic martensitic grade which contains 11.5% chromium, offering both exceptional wear and corrosion resistance. AISI 410 Pipe & Tube is ductile and can be formed. SA 268 TP410 is magnetic in various conditions. ASTM A268 TP410 Seamless Tubing has great corrosion resistance along with wide strength and hardness. In the annealed condition, SS 410 Tubing is ductile and might be formed. ASTM A268 TP410 Polish Tubes are suitable in environments containing nitric acid and sulfuric acid, weak or diluted acetic acid, naptha. TP 410 Stainless Steel Tube & pipe is commonly used for applications which involve high strength, mild corrosion, and heat resistance. SS 410 Seamless Tube is good machined in the annealed condition at surface speeds of 60 – 80 feet (18.3 – 24.4m) per minute.
Standards | Stainless Steel 410/S Pipe & Tube |
|---|---|
| ASTM Specification | ASTM A312 TP410, ASTM A213 TP410S |
| 410 Stainless Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| 410 Stainless Steel Welded Pipe Size | 5.0 mm – 1219.2 mm |
| SS 410 EFW Pipe size | 5.0 mm – 1219.2 mm |
| SS 410 Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| SS 410 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| 410 Stainless Steel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| 410 Stainless Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| AISI 410 Pipe Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| SS 410 Tube wall thickness | 0.020" –0.220", (special wall thicknesses available) |
| 410 Stainless Steel Square Pipe Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| SS 410 Square Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Schedule 40 Type 410 Stainless Steel Pipe Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| ASTM A312 Grade TP410 Spiral Tube Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| JIS Sus410 Pipe End | Plain End, Beveled End, Treaded Pipe & Tube |
| Large Diameter Stainless Steel 410 Tube Marking | All Grade 410 stainless steel pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| SS 410 Erw Pipe Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| ASTM A312 Grade TP410 Pitot Tube Specialize in |
|
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Manufacturers of 410 Stainless Steel Pipe |
|
| We can also cut, thread, and groove 410 Stainless Steel Pipe to meet your specifications. Pipe Dimension ANSI/ ASME B36.10, B36.19, B2.1 | |
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | N | |
| 410 | min. | – | – | – | – | – | 11.5 | – | – | – |
| max. | 0.15 | 1.0 | 1.0 | 0.040 | 0.030 | 13.5 | 0.75 | – | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 410 | 480 | 275 | 16 | 92 | 201 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 410 | 1.4006 | S41000 | SUS 410 | – | – | – | – |
|
