| Categories | Temperature Humidity Chamber |
|---|---|
| Brand Name: | ASLI |
| Model Number: | TH-225-F |
| Certification: | CE , ISO , SGS |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Negotiation |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 80 sets per month |
| Delivery Time: | 20workdays |
| Packaging Details: | standard export plywood case |
| Internal Dimension: | W600*H750*D500mm |
| Volume: | 225 Liters |
| Temperature Range: | -70~150C |
| Humidity Range: | 20%R.H. ~ 98%R.H. |
| Temperature Indication relolution: | 0.1 C |
| Temperature Control Accuracy: | +/- 0.5C |
| Temperature rising: | 0.1~3.0 C/min |
| Test Hole: | Dia. 100mm |
| Viewing Window: | W250*D300mm |
| Communication Interface: | RS 485 / RS232 |
Model | TH-80(A~F) | TH-150(A~F) | TH-225(A~F) |
Internal Dimension WxHxD (mm) | 400x500x400 | 500x600x500 | 600x750x500 |
External Dimension WxHxD (mm) | 950x1650x950 | 1050x1750x1050 | 1200x1900x1150 |
Temperature Range | Low Temperature(A:25℃ B:0℃ C:-20℃ D:-40℃ E:-60℃ F:-70℃) High Temperature 150℃ | ||
Humidity Range | 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need
Dehumidifier) | ||
Indication relolution /Distribution uniformity of temperature and
humidity | 0.1℃; 0.1% R.H/±2.0℃; ±3.0% R.H. | ||
Control Accuracy of Temperature and Humidity | ±0.5℃; ±2.5% R.H. | ||
Temperature Rising/ Falling Velocity | Temperature rising approx. 0.1~3.0℃/min ; temperature falling approx. 0.3~1.0℃/min; ( Falling Min.1.5℃/min is optional) | ||
Approx. Weight (Kg) | 150 | 180 | 250 |
1. Graceful appearance, circularly shaped body, surface treated
with mist strips . Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for viewing sample under
test, with interior light
3. Double-layer-insulated airtight doors, able to insulate the
internal temperature effectively.
4. Water supply system that is externally connectable, convenient
for refilling water into the humidifying pot and automatically
recyclable.
5.French Tecumseh is used as compressor, with environment friendly
refrigeration R23 or R404A
6. LCD display screen, capable of displaying the measured value as
well as the set value and time.
7. The control unit has the functions of multiples segment program
editing, with quick or ramp rates control of temperature and
humidity.
8. Casters are provided for ease of mobility, with strong
positioning screws.
We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechanical vibration and shock testing machine. Heating Rate 0.1~3.0 C/min Temperature Humidity Climate Control Test Chamber is our star products , and we had obtained the CE certification for this machine .
|
