W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel

Categories	Steel Forging Parts
Brand Name:	PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Model Number:	X120Mn12, 1.3401, ASTM A128, Z120M12, X120Mn13, Creusabro® M
Certification:	SGS, TUV, BV, ISO, MTC
Place of Origin:	China
MOQ:	600kg
Price:	Negotiations
Payment Terms:	T/T
Supply Ability:	50000KGS/Month
Delivery Time:	Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
Packaging Details:	Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
Product Name:	W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel
Characteristic:	High hardness
Heat treatment condition:	Cold draw, hot forged, etc
Processing methods:	Machined, Milled, Ground, etc
Available Shapes:	Strips, Wire rod, Sheet Steel, etc
Surface:	Peeled, Black, etc

Contact Now

Add to Cart

Company Info.

Mianyang Baoheng New Material Technology Co.,Ltd

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel

W-Nr 1.3401 DIN X120Mn12 Austenitic Manganese Hot Rolled Steel

Product Information

X120Mn12 is a high manganese steel with an austenitic structure, also a non-magnetic steel, characterized by a high carbon content - 1.00-1.20% on average, and a high manganese content - approx. 12%.

Size Range

Round bar / Wire rod (Diameter): 5.0 mm to 500 mm
Square bar / Flat bar: 1.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T3 - 1000 mm X W8 - 1000 mm X L800-12000 mm
Sheet steel via cold rolled: T5.0 - 10 mm X W5 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T1 - 8 mm X W10 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

X120Mn12/1.3401	GX120Mn13/1.3802	ASTM A128
--	--	--
C(％): 1.10~1.30 Si(％): 0.3~0.5 Mn(％): 12.0~13.0 P(％)≤: 0.10 S(％)≤: 0.04 Cr(％): ≤1.5 Ni(％): ≤1.0 Mo(%): -	C(％): 1.05~1.35 Si(％): 0.3~0.9 Mn(％): 11.0~14.0 P(％)≤: 0.06 S(％)≤: 0.045 Cr(％): - Ni(％): - Mo(%): -	C(％): 1.05~1.35 Si(％): ≤1.00 Mn(％): ≥11.0 P(％)≤: 0.07 S(％)≤: - Cr(％): - Ni(％): - Mo(%): -

X120Mn12/1.3401 Mechanical Properties

Tensile strength, Rm/MPa: ≥900
Yield strength, Rp/MPa: ≥400
Elongation/%: ≥40
Reduction of area, ψ/%: ≥200
Hardness, HBW: --

Applications
X120Mn12/1.3401 is mainly used in crushing and earthmoving equipment in railway and shot blasting industry, primary rock crushing equipment
