| Categories | Lithium Manganese Dioxide Battery |
|---|---|
| Brand Name: | OEM |
| Model Number: | CR15H270 |
| Certification: | UL |
| Place of Origin: | China |
| MOQ: | 10pcs |
| Price: | Bargain |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000pcs/days |
| Delivery Time: | 5-7 working days |
| Packaging Details: | cartons |
| Shape: | Cylinder |
| Part number: | CR15H270 CR2 |
| Voltage: | 3V |
| Discharge capacity: | 800±50 mAh |
| Material: | limno2 battery |
| Samples: | Available |
| Company Info. |
| Lu’s Technology Co., Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
Battery CR2 3V CR15H270 850mah For Camera Battery 3v 850mAh for Motion Sensors cr2
CR2 lithium batteries also known as DLCR2 ELCR2 CR15H270 are available here . Each battery is 3V and are now popular in all types of electronic equipment.
CR2 Lithium Battery CR15H270(CR2)
CR2 Size Dia*H:0.59x1.06 (inch)
CR2 3V Battery Can Not Be Recharged .
CR2 Advantages: High energy density ; High open circuit voltage ;Wide range of operating temperature; Stable operating voltage and current; Long operating time;Low self-discharge rate (less than 1% per year at 25ºC)
CR2 Lithium Battery Applications:motion sensors ,smoke alarms,alarm system,range finders,timer switch,flashlight,light meters,laser sights,shock collar,tactical light,security system,camera.
Technical parameters
| No. | Items | Characteristics |
| 1 | Nominal Capacity* | 850 mAh |
| 2 | Discharge capacity (continuously discharge under 10mA,till 2.0V end voltage) | 800±50 mAh |
| 3 | Nominal Voltage | 3V |
| 4 | Operating Temperature range | -40～+85℃ |
| 5 | Max. Pulse Current | 2500 mA |
| 6 | Max. Continuous Discharge Current | 1000 mA |
| 7 | Structures | Manganese dioxide cathode, lithium anode, organic electrolyte, polypropylene separator and stainless steel cell can and cap, etc. |
| 8 | Weight for Reference | About 11g |
Outline figure is shown as follow
| Model | Max. diameter Ф1 ( mm ) | Max. diameter Ф2 ( mm ) | Max. height H1 ( mm ) | Min. height H2 ( mm ) |
| CR2 | 15.6 | 6. 5 | 27.0 | 0.7 |
Key features:
High and stable operating voltage
Superior drain capability
Low self-discharge rate (less than 3% after 1year of storage at +20 )
Optional stainless steel container for low magnetic and nickle
plated steelcontainer for more
safe design
Hermetic glass-to-metal sealing
Notch technology for safety vent is recommended
PTC for finished product is optional
APPLICATION:
Lithium Manganese battery list
| Mode | Voltage (V) | Capacity (mAh) | Discharge Current(mA) | End Voltage(V) | Diameter(mm) | Height (mm) | Weight (g) | Testing Temp.(℃) |
| CR14250 | 3 | 650 | 10 | 2 | 14.5 | 25 | 10 | 23±3 |
| CR14505 | 3 | 1500 | 10 | 2 | 14.5 | 50.5 | 17 | 23±3 |
| CR17335 | 3 | 1500 | 10 | 2 | 17 | 33.5 | 17 | 23±3 |
| CR17450 | 3 | 2000 | 10 | 2 | 17 | 50.5 | 23 | 23±3 |
| CR17505 | 3 | 2500 | 10 | 2 | 17 | 50.5 | 25 | 23±3 |
| CR17345(CR123A) | 3 | 1500 | 10 | 2 | 17 | 34.5 | 17 | 23±3 |
| CR11108(CR1/3N) | 3 | 160 | 2 | 2 | 11.6 | 10.8 | 3.3 | 23±3 |
| CR15H270(CR2) | 3 | 850 | 10 | 2 | 15.6 | 27 | 11 | 23±3 |
| CR-P2 | 6 | 1500 | 10 | 4 | 35x19.5x36 | 38 | 23±3 | |
| 2CR5 | 6 | 1500 | 10 | 4 | 34x45x17 | 38 | 23±3 | |
| CR-V3 | 3 | 3000 | 20 | 2 | 29x14.5x53 | 38 | 23±3 | |
|
