| Categories | Smart OPS PC |
|---|---|
| Brand Name: | INGSCREEN |
| Model Number: | I7-10510U |
| Certification: | CE CB FCC ROHS ISO9001 |
| Place of Origin: | Guangdong |
| MOQ: | 1 |
| Price: | $135-$160 /Unit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 Pcs/Per month |
| Delivery Time: | 5 workdays |
| Packaging Details: | Carton, Wooden rack & Wooden box |
| Name: | Smart OPS PC |
| Size: | 195*180*30mm |
| CPU: | I7-10510U |
| RAM: | DDR4 4G |
| ROM: | 128G |
| Cache: | 8MB |
| Max.frequency: | 4.9 Ghz |
| Core: | 4 |
| Company Info. |
| Ingscreen Technology Limited |
| View Contact Details |
| Product List |
Custom embedded i5 i7 fanless mini computer OPS 10th ops PC for interactive whiteboard
However, some users may buy the wrong operating system for their interactive flat panel display, because there are mainly two sizes of operating systems on the market. In 2010, Intel introduced the Open Pluggable Specification (OPS) to standardize the system architecture between displays and media players. Since its release, OPS has quickly become the standard for creating integrated display solutions. In 2015, Intel specially developed a new and larger operating standard to meet market demand. They are all 80 pins, but OPS-C (abbreviation of OPS China) is slightly larger.
OPS size is 180 x 30 x 118 mm (width, height, depth)
OPS-C size is 180 x 42 x 195 mm (width, height, depth)
| Mini PC Model | OPS-10U 180*120*30mm European Standards 80pin |
| Processor | Support Comet Lake 10th Generation : I3 10110U,I5 10210U,I7 10510U |
| Network Card | 1*RJ45 lan port, Realtek 8111H Gigabit Ethernet chip, supports Wake-on-LAN and PXE diskless boot function MINI-PCIE port,default support WIFI/3G/4G/Blue-tooth module |
| CPU Brand | Intel |
| Display Output | Support |
| Graphics Card | HD-MI+VGA,Intel HD Graphics.4K UHD DP optional |
| Multi-Graphics Card | Not Support |
| Memory | 2*DDR4 ,support 4G/8G/16G/32G/64G |
| Memory Channel | Dual channels |
| I/O Interfaces | 1*DC-in,1*OPS Slot,1*HD-MI,1*VGA , 2*USB3.1 , 2*USB2.0 , 1*LAN,1*AUDIO,1*ON/OFF,1*RESET,1*CMOS.1*TYPE C |
| Condition | 100%New |
| Storage | Supporting these hard disks: MSATA hard disk:8G/16G/32G/64G/120G; |
| Case Material | Aluminium |
| Color | Black |
| Case Size | 180*120*30MM |
| Audio | Realtek ALC662/660 HD digital audio decoder, 6-channel high-fidelity audio controller 1* Line-out port ,audio output 1*MIC-IN port 1*INT_SPK pin, support 8 Ohm 5 watt amplifier speaker 1*F_AUDIO,Standard audio pin 1*SPDIF pin,Digital audio pin |
| Power Supply | DC12V/DC19V |
| Expansion Slots | 1*Mini-PCIE ,1*MSATA,Supporting Wall Hanging,WIFI Antenna Stick,OPS Daughter Card. |
| Operating System | Windows7, Windows8.1, Windows10, Linux. |
| Working Temperature | -20~60℃ at 0.7m/s air flow. |
| Relative Humidity | 95% |
|
