FZ1800R12HP4 Single Switch IGBT Power Module Infineon Power Module 1200v 1800a

Infineon Power Module IGBT FZ1800R12HP4 1200v 1800a Single Switch Igbt Module Soft-Switch

Applications

• • HighPowerConverters
• • MotorDrives
• • WindTurbines
• Specifications

• Parametrics	FZ1800R12HP4_B9
  Configuration	Single switch
  Dimensions (width)	140 mm
  Dimensions (length)	190 mm
  Housing	IHM B
  IC(nom) / IF(nom)	1800 A
  IC max	1800 A
  Qualification	Industrial
  Technology	IGBT4 - P4
  VCE(sat) (Tvj=25°C typ)	1.7 V
  VCES / VRRM	1200 V
  VF (Tvj=25°C typ)	1.8 V
  Voltage Class max	1200 V

Features

• ExtendedOperationTemperature

• LowSwitchingLosses

• LowV

• UnbeatableRobustness

• VCEsatwithpositiveTemperatureCoefficient

• 4kVAC1minInsulation

• PackagewithCTI>400

• HighCreepageandClearanceDistances

• HighPowerDensity

• IsolatedBasePlate

• StandardHousing
