Categories | Universal Testing Machine |
---|---|
Brand Name: | lixian |
Model Number: | HZ-1007A |
Certification: | CE/ISO/ASTM/ROSH |
Place of Origin: | China |
MOQ: | 1 |
Price: | negotiate |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | negotiate |
Delivery Time: | 7 days |
Packaging Details: | wood |
Model: | HZ-1007A |
Accuracy: | 0.5grade |
Maximum Load: | 2KN high-precision sensors from U.S.A. |
Volume: | 450 *550 *1400mm |
Motor: | Panasonic Servo Motor |
Test speed: | 50-300mm / min |
Warranty: | 1 Year |
Power: | Electronic |
Usage: | Universal Testing Machine,Tensile Testing Machine |
Application: | Steel,fiber,fabric,zipper ;universal tester |
Standard: | BS.EN.ASTM,DIN,ASTM,ASTM E8/A370/ISO 75001,ISO |
Model | HZ-1007A Tensile Strength Tester Machine |
Maximum load | 2kn |
Capacity choice | 2000kg or less than can be self-selected |
Unit | KG,N,LB, TON can be exchanged. |
Measurement system | Load cell + HZ-2000 |
Accuracy load of measurement | the load cell + HZ-2000 screen ± 0.5% (full range of 5% -100%) |
Resolution | 1 / 50000 |
Maximum test stoke | About 500mm (excluding gripper, can be customized) |
Test speed | 50-300mm/min with stepless speed and 5 fixed-speed (can be
customized) |
Data sampling frequency | 200times/sec |
Display | HZ-2000 dark blue LCD display, membrane touch keys, with the
following functions. |
Machine size | 45x55x140cm (length*width*height) |
Weight | 75KG |
Ratio of Breakpoint | from 0 ~ 99%, which the user can set according to different
materials to stop the machine, realizing stop machine at any position. |
Safety | The system would shut down if overload or over-trip. |
