GH4145 Nickel Based Welding Wire Inconel 750 Round Bar Tube Sheet

Categories Inconel Alloy
Brand Name: KAIXIN
Model Number: KX-Alloy INx750
Certification: ISO9001:2015
Place of Origin: China
MOQ: 200KG
Price: To negotiate
Payment Terms: T/T, L/C
Supply Ability: 50~80 TONS per MONTH
Delivery Time: 45~60days
Packaging Details: Wooden Box, size as per guests' request
Shape: Wire,Strip,Rod,Pipe,Plate
Alloy Type: Nickel Chromium Iron
Raw Materials: NI70%,CR14-17%,NB0.7-1.2%,Ti2.25-2.75%
Executive standard: ASTM
Delivery State: Sosoloid
Application: Can be used to manufacture high-temperature spring, disc spring, bolt, fastener
Features: Corrosion resistance and oxidation resistance
Size: Negotiable
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

GH4145 Nickel Based Welding Wire Inconel 750 Round Bar Tube Sheet

KX Inconel GH4145 Nickel Alloy Wire Round Bar Tube Steel Sheet Light Rod on Inconel Alloy


Product Description and Application

GH4145 Similar name: NiCr15Fe7TiAl(Germany),NC15FeTNbA(France),NCF750 (Japan)

GH4145 alloy is mainly aged strengthened nickel-based superalloy with good corrosion resistance and oxidation resistance below 980℃, high strength below 800℃, good relaxation resistance below 540℃, but also has good formability and welding properties. The alloy is mainly used to manufacture plane springs and helical springs with high strength and resistance to relaxation for aero-engines operating below 800℃. It can also be used to manufacture turbine blades and other parts.


Process Performance and Requirements


  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)


  • Product Chemical Composition

Alloy%NiCrFeNbCoCMnSiSCuAlTi
GH4145Min145.00.70.42.25
Max70179.01.21.000.081.000.50.010.51.02.75

  • Product Physical Property

Density8.28 g/cm3
Melting Point1393-1427℃

  • Product Mechanical Property

Alloy

Tensile Strength

Rm N/mm2

Yield Strength

RP0.2N/mm2

Percentage Elongation

A5 %

Brinell Hardness

HB

Solution Treatment126786825≤400

  • Productive Process


  • Professional Customization

Cold-drawn Wire¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire¢5.5~¢20mm(Delivery in rolls)
Stripthickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm

Hot-rolled Burnishing¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing¢2.5~18mm,L1000-8000mm
Seamless Tube¢1~275mm,wall thickness 0.2~30,L1000-8000mm
