| Categories | Pharma Water System |
|---|---|
| Brand Name: | CHONGYANG |
| Model Number: | CY-ROE-2000L/H |
| Certification: | ISO ,CE |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiation |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
| Delivery Time: | With 30-40 Days |
| Packaging Details: | According to export standard |
| Capacity: | 100Liter/Hour---10,000Liter/Hour |
| Control Parts: | SIEMENS PLC +HIM |
| Flow Meter: | KROHNE |
| Material: | Stainless Steel 304 ,316L |
| OEM/ODM: | Available |
| Power Supply: | 380V/50HZ,400V/60HZ |
| Product Name: | Pharma Water System |
| Standard: | FDA,cGMP,GMP,USP |
| Pump: | Grundfos ,CNP |
| RO Membrane: | DOW,HYDRANAUTICS |
Product Name:High Temperature Reverse Osmosis System EDI For Pharmaceutical Industry
CHONGYANG WATER MAIN PROCESS:
The Raw Water Inlet►The Raw Water Tank►The Raw Water Pump►Plate Type Heater Exchange►The Multi-medium Filter►Activated Carbon filter►Softener►Security Filter ►The First Stage High Pressure Pump ►The First Stage RO Membrane ►The Second Stage High Pressure Pump ►The Second Stage RO ►EDI ►Purified Water Tank►Conveying Pump (VFD)►The Used Water Point►Tube type heating exchanger(Pasteurization for purified water tank and distribution system ►The return water on end of loop is back to purified water tank
Pharma Water System Standard :
| USP | Ph. Eur. | ChP | ||
| TOC | ppm C | ≤ 0.50 | ≤ 0.50 | Same as Ph. Eur. |
| Conductivity | μS/cm | ≤ 1.3 (25°C) | ≤ 4.3 (20°C) | Same as Ph. Eur. |
| Nitrate (NO3) | - | ≤ 0.2 ppm | ≤ 0.000006% | |
| Aerobic bacteria | CFU/100 ml | ≤ 100 | ≤ 100 | Same as Ph. Eur. |
| Heavy metals | - | ≤ 0.1ppm Pb | ≤ 0.00001% |
CHONGYANG WATER SPEC.& TYPE :
| Water Output(L/H) | Feed Water(M3/H) | Water Production Rate% | Desalination Rate% | Water Working Temperature °c | |
| CY-RO-500 | ≥500 | 1.35-1.4 | ≥75% | 98% | 10-25 |
| CY-RO-1000 | ≥1000 | 2-2.2 | ≥75% | 98% | 10-25 |
| CY-RO-2000 | ≥2000 | 4-4.3 | ≥75% | 98% | 10-25 |
| CY-RO-3000 | ≥3000 | 5.3-5.8 | ≥75% | 98% | 10-25 |
| CY-RO-4000 | ≥4000 | 7-7.6 | ≥75% | 98% | 10-25 |
| CY-RO-6000 | ≥6000 | 10.6-11.5 | ≥75% | 98% | 10-25 |
| CY-RO-8000 | ≥8000 | 14.2-17 | ≥75% | 98% | 10-25 |
| CY-RO-10000 | ≥10000 | 17-19 | ≥75% | 98% | 10-25 |
FAQ:
1. Questions :Is the circulating system important for Pharma Water System ?
Answer : Sure . Circulating system design is an important for purified water system .A one-way system is basically a "dead-leg " .
2. Questions : Can the purified water system be used for cosmetic industry ?
Answer : With improvement of living conditions, The high level cosmetic series need to pharma class water treatment system .
3.Questions: Do there need diaphragm valve on sampling water place ?
Answer:Sure .
|
