Nema 17 Linear Actuator Stepper Motor For Mechanical Transportation

Nema 17 Linear Actuator Stepper Motor For Mechanical Transportation

The screw mechanical transmission can convert the rotational motion of the motor into linear motion, providing higher torque output.

The NEMA 17 through screw stepper motor can provide more stable and reliable performance.

Features:

• Bipolar or unipolar versions available

• Hybrid stepper construction

• Our engineers will reach out to you within 48 hours to offer the optimal solution

• CE and RoHS approved

• We provide customized services and are open to contract manufacturing

Motor Specifications

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Shaft Radial Play:0.02Max. (450g-load)

Shaft Axial Play:0.08Max. (450g-load)

Max. radial force:28N (20mm from the flange)

Max. axial force):10N

Torque Curves

Submodels

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Please click the "Get a quote" button below to tell us your requirements.
