Standard Welding Nickel Alloy Incoloy 925 926 825 800 Wire Per Kg Nickel Wire

Standard Welding Nickel Alloy Incoloy 925 926 825 800 Wire Per Kg Nickel Wire

Standard Welding Nickel Alloy Incoloy 925 926 825 800 Wire Per Kg Nickel Wire
Standard Welding Nickel Alloy Incoloy 925 926 825 800 Wire Per Kg Nickel Wire
Categories Nickel Welding Wire
Brand Name: Victory
Model Number: ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-7,ERNiCr-3
Certification: CE,ROHS,ISO 9001
Place of Origin: China
MOQ: 15
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Delivery Time: 5-21 days
Packaging Details: Spool package with Carton box, Coil package with polybag
Material: Ni, Mo, Cr
Elongation: ≥22 %
Density: 8.60 g/cm3
Tensile strength Rm N/mm²: ≥600
Yieldstrength R P0. 2 N/mm²: ≥360
Melting point: 1310-1360℃
Certificates: AWS A5.14 / ASME SFA A5.14
Contact Now
Company Info.
Changzhou Victory Technology Co., Ltd
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Standard Welding Nickel Alloy Incoloy 925 926 825 800 Wire Per Kg Nickel Wire

This is a series of welding wire products including ERNiCrMo-3, ERNiCrMo-4, ERNiCrMo-13, ERNiCrFe-3, ERNiCrFe-7, ERNiCr-3, ERNiCr-7, ERNiCu-7 and ERNi-1. These welding wires are commonly used for welding alloy steels, stainless steels, nickel alloys and copper alloys. They offer excellent corrosion resistance, high temperature strength and good welding properties, making them suitable for a variety of welding applications, including the aerospace, chemical, petroleum and energy industries. These welding wire products can provide stable arc and good metal transfer during the welding process, help obtain high-quality welds, and maintain good mechanical properties and corrosion resistance of the welded joints. Whether in high temperature environments or corrosive media, these products provide reliable welding solutions.

Chemical Properties

C Si Mn Cr P Ni
≤0.01 ≤0.2 ≤0.5 22.0-24.0 ≤0.015 Rem
Al Mo Fe Cu S Co
0.10-0.40 15.0-16.50 ≤0.5 ≤0.1 <0.01 <0.20

Typical Welding Parameters
Diameter Process Volt Amps (flat) Amps (V/OH)
inch (mm)
0.035 0.9 GMAW 26-29 150-190 Spray Transfer 100% Argon
0.045 1.2 GMAW 28-32 180-220 Spray Transfer 100% Argon
1/16 1.6 GMAW 29-33 200-250 Spray Transfer 100% Argon
1/16 1.6 GTAW 14-18 90-130 100% Argon
3/32 2.4 GTAW 15-20 120-175 100% Argon
1/8 3.17 GTAW 15-20 150-220 100% Argon

Tensile Strength 109 Ksi 790 MPA
Yield Strength 68 Ksi 470 MPA
Elongation 40-45%
Density g/cm3 8.60 g/cm3
Melting Point ℃ 1300-1360℃
Coefficient of Expansion. 21-93 Co, μm/m * Co 11.90

Item
ERNiCrMo-3
ERNiCrMo-4
ERNiCrMo-13
ERNiCrFe-7
ERNiCr-3
ERNiCu-7
ERCuNi
ERNi-1
C
0.1
0.02
0.01
0.04
0.1
0.15
0.03
0.15
Mn
0.05
1
0.5
1
2.5-3.5
4
0.5-1.0
1
Fe
5
4-7
1.5
7-11
3
2.5
0.65
1
P
0.02
0.04
0.015
0.02
0.03
0.02
0.01
0.03
S
0.015
0.03
0.005
0.015
0.015
0.015
0.01
0.015
Si
0.05
0.08
0.1
0.5
0.5
1.25
0.15
0.75
Cu
0.5
0.5
N/A
0.3
0.5
rest
rest
0.25
Ni
≥58
rest
rest
rest
≥67
62-69
30-32
≥93
Co
N/A
2.5
0.3
N/A
N/A
N/A
N/A
N/A
Al
0.4
N/A
0.1-0.4
1.1
N/A
1.25
0.15
1.5
Ti
0.4
N/A
N/A
1
0.75
1.5-3
0.5
2-3.5
Cr
20-23
14.5-16.5
22-24
28.5-31
18.0-22.0
N/A
N/A
N/A
Nb+Ta
3.5-4.15
N/A
1.8-2.5
0.01
2.0-3.0
N/A
N/A
N/A
Mo
8.0-10
15-17
15-16
0.5
N/A
N/A
N/A
N/A
V
N/A
0.35
N/A
N/A
N/A
N/A
N/A
N/A
W
N/A
3.-4.5
N/A
N/A
N/A
N/A
N/A
N/A
Rest
≤0.50
≤0.50
≤0.50
≤0.50
≤0.50
≤0.50
≤0.50
≤0.50
