| Categories | Low Pressure Die Casting Machine |
|---|---|
| Brand Name: | DZ |
| Model Number: | RD-5040-S |
| Place of Origin: | CHINA |
| Certification: | CE ISO |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 3 sets per month |
| Delivery Time: | 20 work days |
| Packaging Details: | wood |
| Cooling System Water Temperature: | 20±2℃ |
| Furnace Inductors: | 3*35KW |
| Equipment Size:L*W*H: | 5200*5000*3600mm |
| Max. Die Opening Stroke: | 370mm |
| Hydraulic Motor Power: | 8.7KW |
| Total Power: | 125KW |
| Cooling System Flow: | ≥400L/Min ≤600L/Min |
| Total Weight: | 13T |
| Company Info. |
| Xiamen DingZhu Intelligent Equipment Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
| Parameter | Value |
|---|---|
| Equipment Size:L*W*H | 5200*5000*3600mm |
| Furnace Capacity | 1800KG |
| Gas Pressure | 0.5bar |
| Max. Force of Ejector | 500kg |
| Gas Flow | 0.225m³/h |
| Max. Die Weight | 200Kg |
| Cooling System Pressure | 3-5bar |
| Hydraulic Motor Power | 8.7KW |
| Cooling System Water Temperature | 20±2℃ |
| Max. Die Ejector Stroke | 48mm |
Suitable for bathroom accessories, faucets, water meters and valves and other brass casting.
Low Pressure Die Casting Machine is packaged and shipped in such a way as to ensure the safety and security of the product. An important consideration when shipping a Low Pressure Die Casting Machine is to ensure that it is packaged securely and can withstand the rigors of transportation. The common packaging materials used for Low Pressure Die Casting Machines include:
The Low Pressure Die Casting Machines are shipped either by ground, air, or sea. Depending on the size and weight of the machine, the shipping method may vary. Generally, larger and heavier machines are shipped by sea, while smaller and lighter machines are shipped by air. Delivery time may vary based on the shipping method chosen and the destination.
|
