Name: Welded Wire Mesh Galvanized Steel Gabion Box Baskets 1mx1mx1m
Brand: Bingze
Price: 5 USD

Product Details
Company Profile

Welded Wire Mesh Galvanized Steel Gabion Box Baskets 1mx1mx1m

1mx1mx1m Welded Wire Mesh Galvanized Steel Gabion Box Baskets Gabion Mesh

Product Description ----------------------------------------------------------------------------------------------------------------------------------------------------------

Welded Gabion is made of welded wire mesh panel, it is assembled with a spiral-shaped wire to assemble the front and rear panels, the bottom plate and the partition after welding, and is packed together with the mesh cover. All the caged products that are folded and tied are an independent individual.

Welded Mesh Gabions are constructed using square electro welded weld mesh panels of high tensile steel. They are increasing in popularity due to their comparative ease and speed of installation. They are an economical environmental solution for structural retaining walls and coastal defences. They are particularly suited for use in retaining walls due to their permeability and flexibility. The permeability enables groundwater to flow through freely when most other retaining wall types will retain ground water causing hydrostatic pressure to build up behind the wall. Hydrostatic pressure buildup may result in the wall failing and collapsing. The flexibility allows gabions to deform a little without damage when in comparison rigid retaining walls such as concrete walls would have cracked and crumbled.

Can be Assembled by springs, C-rings. Reinforced by Hooks.

Product Specifications --------------------------------------------------------------------------------------------------------------------------------------------

specification of Gabion Box
Gabion size(m)	Mesh opening	Wire diameter	Surface treatment
1×1×1	50 x 50mm 75 x 75mm 80 x 80mm 100 x 100mm	3-6mm	Galvanized Galfan PVC coated
2×1×1		3-6mm
3×1×1		3-6mm
0.5×0.5×0.5		3-6mm
1×0.5×0.5		3-6mm
1×1×0.5		3-6mm
2×1×0.5		3-6mm

Our Gabion box is made from strengthened hot dipped galvanized or zinc-aluminium coated steel which delivers exceptional corrosion resistance.

Installation Methods ---------------------------------------------------------------------------------------------------------------------------------------------------

There are two common installation methods for gabion box.

1. Gabion Boxes installation by spring wires.

Welded Gabion Box Accessories
1	Welded mesh panel	6 pcs
2	Spiral spindle	12 pcs
3	Corner stiffer	2-8pcs
4	Diaphgram	1 pc per meter

2. Gabion Boxes installation by C clips

Using C Clips instead of spring wires is also a common installation method of gabion boxes. This installation method is simpler and more economical than spring wires. Ir is also a good choice for customers.

Gabion Box Advantage ----------------------------------------------------------------------------------------------------------------------------------------------

Technology

Material: low carbon steel wire
Wire diameter:3.0-6.0mm
Surface: passivation and plasticization of electro-galvanized, hot-dip galvanized, plastic coated, dip-coated or Galvan
Color: silver, green. etc
The wire used to manufacture double twisted gabion wire mesh is soft annealed, mild steel wire provided with heavy zinc coating as
per EN 10244/ASTM A 641 to prevent corrosion. In case of use in aggressive environments, it is further extruded with 0.5mm thick
PVC Coating.

Features

Durable structure with greater strength.
Better shape control.
Utmost corrosion resistance.
Easy to assemble.
Aesthetically appearance.

Welded Mesh Gabions are constructed using square electro welded weld mesh panels of high tensile steel. They are increasing in popularity due to their comparative ease and speed of installation.

They are an economical environmental solution for structural retaining walls and coastal defences.

Product Applications ------------------------------------------------------------------------------------------------------------------------------------------------------

Gabion planter.
Retaining wall.
Fireplaces.
Slope protection.
Landscape construction.
Road protection.

Company Profile --------------------------------------------------------------------------------------------------------------------------------------------------------------

Anping Bingze Wire Mesh Products Co., Ltd. has focused on the production and research and development of stainless steel wire mesh for 25 years. It is a manufacturer integrating production, processing, distribution and wholesale. The main products include galvanized welded wire mesh,stainless steel welded wire mesh,PVC welded wire mesh,crimped wire mesh,galvanized woven wire mesh,stainless steel woven wire mesh,chain link fence,steel fence,welded wire mesh fence panels,PVC euro fence,358 anti-climb fence,razor wire,Hesco Barrier,Gabion Box and so on.Since its beginning,we have been working at four points, they are High Quality,Quick Delivery,Better Price and Thorough Service,Rely on the product quality and our credit standing, we have got favourable comments from the customers.The company introduces precise making machines and technics,combinning scientific inner managing method and quality control system.Since the year it was established ,we developed our powder and credit standing and got reliances of our customers in home and abroad.Our products is checking by very high standeard, and the qualified ones leaved the factory to the whole county an some aabroad countries,such as Southeast Asia,Middle East,Ameria,Japan,and some Africa countries.

Certifications --------------------------------------------------------------------------------------------------------------------------------------------------------------------

Heavy Duty Defensive Bags Sand Wall Barrier For A Shooting Range Hesco Barrier 11

FAQ ---------------------------------------------------------------------------------------------------------------------------------------------------------------

Q: How long is your delivery time?
Generally it is 3-7 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q:Do you provide samples?
Yes, we can provide the product samples for your test.Its free and freight should be collected by your side.

Q:How can I know the completion of my order?
Deposit payment---start production---transfer infro to logistic---book shipment--inform customer ETD&ETA---load container---balance payment---send documents

Q:How can I know whether you are a reliable company?
We have been in this business line since 1987,with too much exporting experience. Above listed our certifications.

Contact Me --------------------------------------------------------------------------------------------------------------------------------------------------------------

Product Tags:


*From:	Your email address is incorrect!
*To:	Anping Bingze Wire Mesh Products Co.,Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Gabion Box
Brand Name:	Bingze
Model Number:	WGB20231009
Certification:	ISO9001-2015
Place of Origin:	Anping,China
MOQ:	1 square meter
Price:	5-15 dollars
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	500 Square Meter/Square Meters per Day gabion wire
Delivery Time:	10-15days
Packaging Details:	1) carton 2) pallet 3) as customer's requirement
Product Name:	Gabion Box
Product Gabion L x W x H:	1mx1mx1m,etc
Product Wire Gauge:	3.8-5.0mm
Product Hole Shape:	Square
Surface treatment:	Electro or hot-dipped galvanized,PVC powder coated
Product Gabion stone basket:	Welded
Frame Material:	Metal
Product Application:	Gabion Planter
