Stainless Steel Welded Tube For Medcial Needle Injection And Infusion Application

Stainless Steel Welded Tube for Medcial Needle, Injection and Infusion application
Injection needle tube and Infusion needle tube produced by weldding from stainless steel strip , after weldding , then arrange coil hydro forming cold drawing with inner plug, final the tube insider and outside both surface are smooth , and tolerance also excellent .
Manufacturing Process of Stainless Steel Pipes/Tubes:
The process commences with the formation of welded mother tube on the tube mill from imported and tested prime quality stainless steel strips. The latest TIG multi electrode welding technique is employed for superior weld quality and 100% Fusion, with argon purging, No filler metal added.

Gauge Number	Needle Nominal O.D.	Needle Nominal I.D.	Needle Wall Thickness	Needle Dead Volume
Gauge Number	(mm)	(mm)	(mm)	(µL/25.4 mm)
34 gauge needle	0.159	0.051	0.051	0.052 µL/25.4 mm
33 gauge needle	0.21	0.108	0.051	0.233 µL/25.4 mm
32 gauge needle	0.235	0.108	0.064	0.233 µL/25.4 mm
31 gauge needle	0.261	0.133	0.064	0.353 µL/25.4 mm
30 gauge needle	0.312	0.159	0.076	0.504 µL/25.4 mm
29 gauge needle	0.337	0.184	0.076	0.675 µL/25.4mm
28 gauge needle	0.362	0.184	0.089	0.675 µL/25.4 mm
27 gauge needle	0.413	0.21	0.102	0.876 µL/25.4 mm
26s gauge needle	0.474	0.127	0.178	0.322 µL/25.4 mm
26 gauge needle	0.464	0.26	0.102	1.349 µL/25.4 mm
25s gauge needle	0.515	0.153	0.178	0.464 µL/25.4 mm
25 gauge needle	0.515	0.26	0.127	1.349 µL/25.4 mm
24 gauge needle	0.566	0.311	0.127	1.93 µL/25.4 mm
23s gauge needle	0.642	0.116	0.267	0.268 µL/25.4 mm
23 gauge needle	0.642	0.337	0.152	2.266 µL/25.4 mm
22s gauge needle	0.718	0.168	0.279	0.563 µL/25.4 mm
22 gauge needle	0.718	0.413	0.152	3.403 µL/25.4 mm
21 gauge needle	0.819	0.514	0.152	5.271 µL/25.4 mm
20 gauge needle	0.908	0.603	0.152	7.255 µL/25.4 mm
19 gauge needle	1.067	0.686	0.191	9.389 µL/25.4 mm
18 gauge needle	1.27	0.838	0.216	14.011 µL/25.4 mm
17 gauge needle	1.473	1.067	0.203	22.715 µL/25.4 mm
16 gauge needle	1.651	1.194	0.229	28.444 µL/25.4 mm
15 gauge needle	1.829	1.372	0.229	37.529 µL/25.4 mm
14 gauge needle	2.109	1.6	0.254	51.076 µL/25.4 mm
13 gauge needle	2.413	1.804	0.305	64.895 µL/25.4 mm
12 gauge needle	2.769	2.159	0.305	93 µL/25.4 mm
11 gauge needle	3.048	2.388	0.33	113.728 µL/25.4 mm
10 gauge needle	3.404	2.693	0.356	144.641 µL/25.4 mm
*mm are nominal

Blood collecting needle tube

Injection needle tube

Dental needle tube

Veterinary needle tube

Irrigating needle tube

Infusion needle tube

Anesthesia needle Tube

Bone marrow needle tube

Guide needle tube

Insulin pen needle

Prismatic needle

Vein detained needle tube

Medical blade needle tube
