| Categories | Alnico Permanent Magnet |
|---|---|
| Brand Name: | UNMAG |
| Place of Origin: | China |
| Delivery Time: | 20-25days |
| Grade: | Alnico 5,8 Is Normally Used |
| BHmax: | 1.13-9 MGOe |
| Material: | Cast Alnico |
| Application: | Generator, Microphone, Measuring Instrument |
| Tolerance: | ±0.05mm |
| Type: | Permanent Magnet |
| Max Operating Temperature: | 550℃ |
| Magnetization Direction: | Axial, Radial, Multi-poles... |
| MOQ: | 100pcs |
| Price: | As negotiation |
| Packaging Details: | cartons,pallets |
| Payment Terms: | T/T L/C |
| Supply Ability: | 20 tons per month for SmCo magnet |
| Company Info. |
| Xiamen Un Magnet Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Alnico permanent magnet is a kind of ferromagnetic material, which is made of aluminum, nickel, cobalt and other metals. It has high magnetic property, high coercive force, excellent temperature stability and corrosion resistance. The Alnico magnets are divided into cast Alnico magnets and Sintered Alnico magnets according to the manufacturing process. Alnico rod magnet, Alnico9, cast Alnico magnet and Alnico5 are commonly used. The Hcj of Alnico magnets is ≥30 KA/m, the tolerance is ±0.05mm, and the BHmax is 1.13-9 MGOe. Alnico permanent magnets have a wide range of applications, such as generators, microphones, measuring instruments, etc.
| Magnetic Properties Of Alnico Magnet | ||||||||||||||
Grade | Equivalent MMPA Class | Remanence | Intrinsic Coercivity | Coercivity | Maximum Energy Product | Density | Reversible Temp. Coefficient | Curie Temp. | Temp.Coefficient | Remark | ||||
| Br | Hcj | Hcb | (BH)max | g/cm3 | α(Br) | TC | TW | |||||||
| mT | Gs | KA/m | Oe | KA/m | Oe | KJ/m3 | MGOe | %/℃ | ℃ | ℃ | ||||
| FLN8 | Alnico3 | 520 | 5200 | 43 | 540 | 40 | 500 | 8-10 | 1.0-1.25 | 6.8 | -0.02 | 760 | 450 | Isotropic |
| FLNG12 | Alnico2 | 700 | 7000 | 43 | 540 | 40 | 500 | 12-14 | 1.5-1.75 | 7 | -0.014 | 810 | 450 | |
| FLNGT18 | Alnico8 | 600 | 6000 | 107 | 1350 | 95 | 1200 | 18-22 | 2.25-2.75 | 7.2 | -0.02 | 850 | 550 | |
| FLNGT28 | Alnico6 | 1000 | 10000 | 57 | 710 | 56 | 700 | 28-30 | 3.5-3.8 | 7.2 | -0.02 | 850 | 525 | Anisotropic |
| FLNG34 | Alnico5 | 1100 | 11000 | 51 | 640 | 50 | 630 | 34-38 | 3.5-4.15 | 7.2 | -0.016 | 890 | 525 | |
| FLNGT31 | Alnico8 | 780 | 7800 | 106 | 1130 | 104 | 1300 | 33-36 | 3.9-4.5 | 7.2 | -0.02 | 850 | 550 | |
| FLNGT38 | 800 | 8000 | 126 | 1580 | 123 | 1550 | 38-42 | 4.75-5.3 | 7.2 | -0.02 | 850 | 550 | ||
| FLNGT42 | 880 | 8800 | 122 | 1530 | 120 | 1500 | 42-48 | 5.3-6.0 | 7.25 | -0.02 | 850 | 550 | ||
| FLNGT33J | Alnico8HC | 680 | 6800 | 151 | 1885 | 140 | 1750 | 33～36 | 4.1-4.5 | 7.2 | -0.02 | 850 | 550 | |
| FLNGT40J | 800 | 8000 | 156 | 1950 | 144 | 1800 | 43~47 | 5.4~5.9 | 7.2 | -0.02 | 850 | 550 | ||
UNMAG Alnico Magnet is a high-performance permanent magnet that is made of an alloy of aluminum, nickel and cobalt. This type of Alnico magnet provides high magnetic flux density, high coercive force and excellent temperature stability. It is widely used in the generation of electricity, microphone, measuring instruments and other applications.
UNMAG Alnico magnet is manufactured from Alnico 5 and Alnico 8 grades to meet customers’ specific requirements. The magnetization direction can be axial, radial, multi-poles or others. Its Hcj value is over 30 KA/m and its maximum operating temperature can reach 550℃.
UNMAG Alnico magnet is produced in China and is usually dispatched within 25-30 days. It has been widely used in various industries, such as aerospace, automotive, electronics and medical, due to its remarkable properties.
UNMAG offers customizable Alnico Permanent Magnet products with Alnico5, Alnico8, and Alnico8 grades typically used. Our Alnico Permanent Magnet products come with a maximum operating temperature of 550℃ and delivery time of 25-30 days.
These magnets are ideal for a wide range of applications, such as generators, microphones, and measuring instruments. The BHmax range for the magnets is 1.13-9 MGOe.
If you are looking for customized Alnico Permanent Magnet products, UNMAG is your one-stop solution.
Alnico Permanent Magnet Packaging and Shipping:
|
