A2FO Fixed Axial piston pumps , High pressure pump , Open circuit pumps

Categories Rexroth Hydraulic Pump
Brand Name: Bosch Rexroth
Model Number: A2FO10
Certification: GS, RoHS, CE, ISO9001
Place of Origin: China
MOQ: 1 pcs
Price: discussible
Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram
Supply Ability: 500pieces/Year
Delivery Time: 5days
Packaging Details: Wooden box
Nominal pressure/Maximum pressure: 400/450 bar
Function: Open circuit
Size: 5-1000
Rate of pressure change RA max: 16000 bar/s
Nominal pressure pnom: The nominal pressure corresponds to the maximum design pressure.
Pressure at suction port S (inlet): 30 bar absolute
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

A2FO Fixed Axial piston pumps , High pressure pump , Open circuit pumps

A2FO Fixed Axial piston pumps , High pressure pump , Open circuit pumps

The pump A2FO is designed to be used in open circuits.
The project planning, installation and commissioning of the axial piston unit requires the involvement of qualified personnel.
Before using the axial piston unit, please read the corresponding instruction manual completely and thoroughly. If necessary, these can be requested from Bosch Rexroth.
During and shortly after operation, there is a risk of burns on the axial piston unit. Take appropriate safety measures (e. g. by wearing protective clothing).
Depending on the operating conditions of the axial piston unit (operating pressure, fluid temperature), the characteristic may shift.

Technical data

Series 6
SizeNominal pressure/Maximum pressure
5315/350 bar
10 to 200400/450 bar
250 to 1000350/400 bar
Open circuit

Features

– Fixed pump with axial tapered piston rotary group of bent-axis design, for hydrostatic drives in an open circuit

– For use in mobile and stationary applications

– The flow is proportional to the drive speed and displacement

– The drive shaft bearings are designed for the bearing service life requirements usually encountered in these areas

– High power density

– Small dimensions

– High total efficiency

– Economical design

– One-piece tapered piston with piston rings for sealing
