Shaft Length 40mm Nema 34 Closed Loop Stepper Motor for Industrial Automation Systems

Categories Closed Loop Stepper Motor
Warranty: 3months-1year
Place of Origin: Chongqing
Brand Name: UMot
Model Number: Nema 34
Phase: 2
Type: Hybrid
Current / Phase: DC 6A/4A/6A
Product Name: Closed Loop Stepper Motor
Rated Current: DC 6A/4A/6A
Rated Voltage: DC 2.43V/12V/3V
Holding Torque: 5/6.5/12N.m
Step Angle: 1.8 Degree
Motor Length: 80/117/150mm
Total Length: 106/143/176mm
Shaft Diameter: 14mm
Shaft Length: 40mm
Motor Weight: 2.8/4.5/6kg
MOQ: 2 pieces
Price: $81.49/pieces 2-39 pieces
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Shaft Length 40mm Nema 34 Closed Loop Stepper Motor for Industrial Automation Systems

High Precision Stepper Motor Nema 34 Close Loop Hybrid Set Nema 34 Closed Loop Stepper Motor With Encoder
Item
Value
Product Name
Closed Loop Stepper Motor
Motor Type
Nema 34
Motor Size
86*80/ 86*117/ 86*150
Rated Current
DC 6A/4A/6A
Rated Voltage
DC 2.43V/12V/3V
Holding Torque
5/6.5/12N.m
Step Angle
1.8 Degree
Motor Length
80/117/150mm
Total Length
106/143/176mm
Shaft Diameter
14mm
Shaft Length
40mm
Motor Weight
2.8/4.5/6kg
