Heat Sealing Composit Films 3 Side Seal Packaging Machine 250 Segments / Min

Categories Three Side Sealing Machine
Brand Name: CJ
Model Number: 500
Place of Origin: China
MOQ: 1set
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 30sets/months
Delivery Time: 20 working days
Packaging Details: plastic film wrapping
Material: composite plasatic film,laminated paper
Bag type: tea bag,candy bag ,powder bag ,food bag ,mask bag etc
Warranty: one year
Voltage: 380V/50HZ
Condition: New
Computerized: Yes
Weight: 4000KG
After-sales service provided: Engineers available to service machinery overseas, Video technical support, Free spare parts, Online support, Field installation
Power(w): 45kw
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Heat Sealing Composit Films 3 Side Seal Packaging Machine 250 Segments / Min

3 sealed powder bag/pouch making machine


Three side sealing pouch making machine is suitable for three-side bag sealing composite film bag making process, and can meet various production requirements of wide range of bag making specifications, high production efficiency and large batch size .


Specifications :

Suitable materialSuitable for various heat sealing composit films
Machine type3 seal with normal double unwinder
Tube sizeMax width:1000mm,max diameter:Ф800mm
Film thickness0.045-0.15mm(single layer)
Bag making speed250 segments/min
Bag making width75-500mm
Bag making length440mm(longitudinal sealing twice)
Control systemPLC control system
Material traction mechanismServo motor system traction
Discharge systemDischarge shaft,tripod or K frame
Braking deviceConstant tension encoder magnetic particle control system
Overall power35kw
Cooling waterAbout 15L/min
Air supply0.6Mpa
Power supplyThree phase 380V/50HZ
WeightApx4000kgs
Dimension11×2×2.2m(L×W×H)

Applications:

Three-side sealing bag has good barrier performance, moisture resistance, low heat sealing and high transparency, suitable for three-sided sealed bag products such as tea, candy, powder bag, snack food, nuts and seeds, rice, makeup bag, mask eye mask bag, medicine bag etc.
