Categories | Seamelss Steel Pipe |
---|---|
Place of Origin: | CHINA |
Brand Name: | Huibo |
Certification: | API 5L |
MOQ: | 10MT |
Price: | FOB, CIF, CFR |
Packaging Details: | in bundles with steel strips |
Delivery Time: | 10-15days after we get the down payments |
Payment Terms: | TT/LC |
Supply Ability: | 5500MT/Month |
Secondary Or Not: | Non-secondary |
Application: | Heat Exchanger or Condenser |
Technique: | Cold Drawn |
Alloy Or Not: | Non-alloy |
1 Production Description:
2 Standards: ASTM A179, ASME SA-179, ASTM A192, GB/T9948-2006,
3 Materials: A179, A450, 10#, 20#, 15CrMo, 1CrMo, 1Cr5Mo or as per your requirements
4 Application: heat exchanger, condenser, boiler
5 Package: in bundles with steel strips
Chemical Composition (%) | Mechanical Properties | Elongation (%) | |||||
C | Mn | P.S | Tensile (MPa) | Yield (MPa) | |||
0.06 ~ 0.18 | 0.27~0.63 | <=0.035 | ≥ 325 | ≥ 180 | ≥ 35 |
Tolerance:
Production | OD(mm) | W.T(mm) | ||
OD(mm) | Tolerance(mm) | OD(mm) | Tolerance(mm) | |
Hot Rolled | ≤101.6 | +0.4~-0.8 | 76~168.3 | +28%~0 |
>101.6~168.3 | +0.4~-1.2 | |||
Cold Drawn | <25.4 | +0.10 | ≤38.1 | +20%~0 |
25.4~38.1 | +0.15 | |||
>38.1~<50.8 | +0.20 | >38.1 | +22%~0 | |
50.8~<63.5 | +0.25 | |||
63.5~<76.2 | +0.30 | |||
76.2~101.6 | +0.38 | |||
>101.6~190.5 | +0.38~-0.64 | |||
>190.5~228.6 | +0.38~-1.14 |
![]() |
