2.4 Inch TFT LCD Screen 240 * 320 8-Bit MCU Interface For Handheld Walkie Talkie

2.4inch TFT LCD screen 240*320,8-bit MCU interface commonly used handheld walkle talkie and other industrial cont

Product Overview

1.1 Description

The LCM-24328-A2 is acolor active matrix TFT-LCD Modelusing amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. It is a transmissive type display operating in the normal black. ThisTFT-LCDhas a 2.4inch diagonally measured active area with 240 horizontalby 320 vertical pixel array. Each pixel is divided into Red , Green, Bluedots which are arranged in vertical stripe and this panel can display 262k colors. This module is commonly used in industrial display terminals such as handheld walkie talkies, facial access control, and work attendance machines.

1.2 Feature

-0.4t Glass(Single)

-Module Design

-RoHS Compliant

-TFT Interface: 8-Bit MCU

Product Size

General specifications

No.	Item	Specification	Unit
1	LCD Size	2.4	inch
2	Panel Type	TN	-
3	Resolution	240x (RGB) x 320	pixel
4	Display Mode	a-Si active matrix,Normally black,transmission type	-
5	Display Number of Colors	262K	-
6	Viewing Direction	12 O'clock	-
7	Contrast Ratio	300:1	-
8	Luminance	300	cd/m2
9	Module Size	42.62(W ) x 60.20(L) x2.35(T)	mm
10	Active Area	36.72(W) x 48.96(L)	mm
11	Pixel Pitch	0.051(W ) x 0.0153(L)	mm
12	Weight	TBD(TYP)	g
13	Driver IC	ST7789T3	-
14	Driver IC RAM Size	240x24x320	bit
15	Light Source	4 LEDs White	-
16	Interface	8-Bit MCU	-
17	Operating Temperature	-20~70	℃
18	Storage Temperature	-30~80	℃

Product Details

        Founded in 2011, Shenzhen Adia Technology Co., Ltd. is a high-tech private enterprise specializing in R & D, production and sales of liquid crystal display (LCD), liquid crystal display module (LCM), TFT color LCD, touch screen and industrial intelligent serial port screen. And can provide a complete set of display screen and display scheme (PCBA).

        With a variety of standard and differential LCD module (LCM), LCD and TFT color display products. Make LCD and LCM of different specifications and technical requirements according to customers' requirements. The products are widely used in the fields of instruments, smart phones, tablets, POS machines, medical devices, car machines, intelligent robots, smart home, intelligent wearable products, UAVs, VR / AR eyes and military products. The products strive to achieve high quality, micro power consumption, fast delivery, reasonable price and timely technical support. With a wide range of well-known enterprises at home and abroad, the products have been widely used and recognized in the market.

        The company attaches great importance to product quality and strictly implements IOS9001 and RoHS management. Stable quality, professional technical support and timely service are the commitment of Adia to customers. Today, the TFT market is more and more widely used, Adia strives to create a professional and well-known manufacturer of TFT display screen industry with consistent adherence, together with customers and suppliers.
