Customizable Nema 23 Closed Loop Motor With 1200mN.M Holding Torque

1. 8 degree Casun Closed Loop Stepper Motor 1200mN.M 57x54mm Stepper Motor With Nema 23 Stepper Motor Controller

Customizable Nema 23 Closed Loop Motor With 1200mN.M Holding Torque And CE Approval

Nema23 Closed Loop Stepper Motor 1200mN.m 4.2Amp with Encoder

Torque: The motor has a holding torque of 1200mN.m (millinewton meters). Holding torque is the maximum torque the motor can produce when stationary.

Current: The motor operates with a current rating of 4.2A (Amperes). This indicates the maximum current the motor can handle without overheating during normal operation.

Encoder: The motor is equipped with an encoder, which is a device used to measure the position and speed of the motor shaft. The encoder provides feedback to the control system, allowing for closed-loop control. This feedback enables better accuracy and control over the motor's position.

Nema23: Nema23 is a standard motor frame size defined by the National Electrical Manufacturers Association (NEMA). It specifies the physical dimensions and mounting interfaces for the motor. Nema23 motors have a flange size of 2.3 inches (57.1 mm) and are commonly used in various applications.

Features:

• Bipolar or unipolar versions available

• Hybrid stepper construction

• Available in single or double shaft versions

• CE and RoHS approved

• Customizations on request

Motor Specifications

Operating Specifications

Motor

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Encoder

can customized

Voltage: 5 v

Output: A + A - B + B -

Torque Curves

Submodels

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

Please click the "Get a quote" button below to tell us your requirements.
