Compact and Lightweight CA-200M Digital Serial Transfer Camera

Categories	Keyence Vision Systems
Brand Name:	Keyence
Model Number:	CA-200M
Place of Origin:	America
MOQ:	1PC
Price:	$99
Payment Terms:	L/C, T/T
Supply Ability:	30PCS
Delivery Time:	3-5WORKS DAYS
Packaging Details:	new in box
Description:	Environment Resistant Keyence Vision Systems 2 Megapixel Camera
Model:	CA-200M
Unit cell size:	4.5 µm × 4.5 µm 0.18 Mil × 0.18 Mil
Image size:	Equivalent to 1/1.8"
Scanning system:	Progressive 56.5 ms
Pixel transfer frequency:	43 MHz
Transfer system:	Digital serial transfer
Lens mount:	C-mount
Weight:	Approx. 75 g (not including lens)

Contact Now

Add to Cart

Company Info.

Xiamen ZhiCheng Automation Technology Co., Ltd

Verified Supplier

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Model		CA-200M
Image element		Monochrome CMOS, High-speed reading using square-pixel
Unit cell size		4.5 µm × 4.5 µm
Valid pixel count		2 megapixel mode: 1600 (H) × 1200 (V), 1 megapixel mode: 1024 (H) × 960 (V)
Image size		Equivalent to 1/1.8"
Scanning system		Progressive 56.5 ms
Pixel transfer frequency		43 MHz
Transfer system		Digital serial transfer
Electronic shutter		Can be set to 0.05 to 9000 msec by specifying the following numerical inputs: 1/15, 1/30, 1/60, 1/120, 1/240, 1/500, 1/1000, 1/2000, 1/5000, 1/10000, 1/20000
Lens mount		C-mount
Enclosure rating		IP64*1
Environmental resistance	Ambient temperature	0 to 45°C
	Relative humidity	35 to 85%RH
Weight		Approx. 75 g (not including lens)
