| Categories | Metal melting furnace |
|---|---|
| Brand Name: | JKZ |
| Model Number: | RH-G100/50 |
| Certification: | ISO9001, CE |
| Place of Origin: | China |
| MOQ: | 1 Set |
| Price: | USD13000-18000/Set |
| Delivery Time: | 30 working days |
| Packaging Details: | Plywood boxes |
| Input voltage: | 3 Phase 380V ±10% 50/60HZ or customized |
| Input current: | 151A |
| Output power: | 100KW |
| Working frequency: | 1-10KHZ |
| Capacity: | 50kg steel/iron |
| Melting time: | 25-30minutes |
Non-ferrous and ferrous metals melting
Precious metal melting, like gold, sliver, platinum,etc.
Semiconductor material melting
Specialized steel, iron, copper melting
Metal alloy melting, like aluminum alloy, zinc alloy, copper alloy,etc.
Other metal melting applications
| RH SERIES TECHNICAL PARAMETERS | |||||
| Model | Input Voltage | Output Power(KW) | Capacity (steel) | Melting time | Melting rate |
| RH-G40A | AC 3P380V | 40 | 15kg | 16-25 minutes | 55kg/hour |
| RH-G60A | AC 3P380V | 60 | 30kg | 20-40 minutes | 100kg/hour |
| RH-G100A | AC 3P380V | 100 | 50kg | 20-40 minutes | 170kg/hour |
| 75kg | 30-50 minutes | ||||
| RH-G150A | AC 3P380V | 150 | 75kg | 20-40 minutes | 290kg/hour |
| 100kg | 30-50 minutes | ||||
| RH-G200A | AC 3P380V | 200 | 100kg | 25-45 minutes | 320g/hour |
| 150kg | 30-50 minutes | ||||
| 200kg | 35-50 minutes | ||||
| RH-G300A | AC 3P380V | 300 | 300kg | 45-60miunutes | 400kg |
| RH-G400A | AC 3P380V | 400 | 500kg | 50-60miunutes | 500kg |
|
