| Categories | Backhoe Wheel Loader |
|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C |
| Showroom Location: | Turkey, Saudi Arabia, Australia |
| Condition: | New |
| Brand Name: | HUAQI |
| Place of Origin: | Shandong, China |
| Type: | Backhoe Loader |
| Moving Type: | Wheel Loader |
| Dimension(Long * Breadth * High): | 5100*1350*2580 mm |
| Warranty: | 1 Year |
| Machine Weight: | 2200 kg |
| Hydraulic Cylinder Brand: | CHAOSHUN |
| Hydraulic Pump Brand: | BOXINHUASHENG |
| Hydraulic Valve Brand: | BOXINHUASHENG |
| Engine Brand: | YUNNEI |
| UNIQUE SELLING POINT: | High operating efficiency |
| Power: | 25 KW |
| Bucket capacity: | 0.4 cbm |
| Machinery Test Report: | Provided |
| Video outgoing-inspection: | Provided |
| Marketing Type: | Ordinary Product |
| Warranty of core components: | 1 Year |
| Core Components: | Engine, Motor, Pump |
| Name: | Backhoe Loader |
| Travel Speed: | 0 - 20 km/h |
| Gradeability: | 30° |
| Min. Turning Radius: | 3,000 mm |
| Working Pressure: | 16 MPa |
| Wheel Tread: | 1,100 mm |
| Product name: | Wheel Mini Excavator |
| Key words: | Backhoe Excavator Loader 4x4 |
| Product type: | 2.2 Ton Wheel Loader |
| Wheel Base: | 1,910 mm |
| Packaging Details: | wooden case |
| Port: | Dalian, Qigndao, Ningbo |
| Supply Ability: | 1000 Set/Sets per Month |
| Price: | $9,800.00/sets 1-19 sets |
| MOQ: | 1 unit |
| Company Info. |
| Shandong Huaqi Machinery Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Model | WZ10-20 | WZ15-26 | WZ20-28 | WZ25-30 | ||||
Dimensions | 5500*1720*2650 mm | 5800*1850*2750 mm | 6200*1960*2800 mm | 6800*2040*2850 mm | ||||
Operating Weight | 3,400 kg | 4,800 kg | 5,400 kg | 6,000 kg | ||||
Travel Speed | 0 - 26 km/h | 0 - 26 km/h | 0 - 30 km/h | 0 - 30 km/h | ||||
Gradeability | 30° | 30° | 30° | 30° | ||||
Min. Turning Radius | 3,500 mm | 4,000 mm | 4,500 mm | 4,500 mm | ||||
Working Pressure | 16 MPa | 16 MPa | 16 MPa | 16 MPa | ||||
Wheel Tread | 1,630 mm | 1,550 mm | 1,630 mm | 1,630 mm | ||||
Wheel Base | 2,670 mm | 2,150 mm | 2,670 mm | 2,670 mm | ||||
Tire | 4 * 20.5-16 | 4 * 23.5-16 | 4 * 16/70 - 20 | 4 * 16/70 - 20 | ||||
Tire Pressure | 250 KPa | 250 KPa | 250 KPa | 250 KPa | ||||
Transmission Type | Hydraulic | Hydraulic | Hydraulic | Hydraulic | ||||
Braking System | Hydraulic | Air Assist | Air Assist | Air Assist | ||||
Engine | ||||||||
Brand & Model | YUNNEI 25GB | YUNNEI 490 | YUNNEI 4102 | YUNNEI 4108 | ||||
Power | 37 kw (50 hp) | 55 kw (75 hp) | 76 kw (104 hp) | 92 kw (125 hp) | ||||
Type | Diesel, 4-cylinder, 4-stroke, Water-cooled | |||||||
Loader Performance | ||||||||
Rated Load | 1,500 kg | 2,000 kg | 2,500 kg | 3,000 kg | ||||
Capacity | 0.75 m³ | 1.0 m³ | 1.25 m³ | 1.5 m³ | ||||
Bucket Width | 1,800 mm | 1,900 mm | 2,000 mm | 2,200 mm | ||||
Max. Dump Height | 2,800 mm | 3,300 mm | 3,500 mm | 3,500 mm | ||||
Max. Dump Distance | 800 mm | 900 mm | 900 mm | 900 mm | ||||
Max. Lift Force | 36 kn (3,672 kg) | 36 kn (3,672 kg) | 42 kn (4,284 kg) | 42 kn (4,284 kg) | ||||
Actuation Time | 12 s | 12 s | 12 s | 12 s | ||||
Backhoe Performance | ||||||||
Capacity | 0.1 m³ | 0.15 m³ | 0.2 m³ | 0.3 m³ | ||||
Bucket Width | 400 mm | 500 mm | 550 mm | 600 mm | ||||
Max. Dig Depth | 2,000 mm | 2,700 mm | 2,600 mm | 2,600 mm | ||||
Max. Dig Height | 3,300 mm | 4,200 mm | 4,300 mm | 4,400 mm | ||||
Max. Dig Radius | 2,900 mm | 4,600 mm | 4,600 mm | 4,600 mm | ||||
Max. Dum Height | 1,850 mm | 2,200 mm | 2,300 mm | 2,300 mm | ||||
Max. Dig Force | 25 kn (2,550 kg) | 28 kn (2,856 kg) | 28 kn (2,856 kg) | 28 kn (2,856 kg) | ||||
|
