concrete reinforcement detector

Categories Industrial Equipment&Supplies
Place of Origin: China
Brand Name: chinacoal
Certification: ISO9001,CE
Packaging Details: standard carton packing
Delivery Time: 7 days for ready goods
Payment Terms: TT,LC,Paypal,Western Union
Supply Ability: 3000 sets/month
MOQ: 1set
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

concrete reinforcement detector

Application:ZBL-R630 Concrete locator/rebar detector/rebar scanner
1. Testing the Location, distribution, direction, and diameter of the rebar and the thickness

of concrete cover in concrete structure projects such as bridges, tunnels, walls etc.

Detecting Ferro magnets in non-ferromagnetic media;
2. Evaluating the quality of construction;
3. Evaluating the integrity and the durability of existing structures;
4. Testing the quantity of rebar when evaluating and developing the old structure;
5. Testing the distribution and direction of electric cables and plumbing inside walls and floors.
Feature:
1. Uni-probe with two detect range:the uniprobe has both a small and large detect range;
2. Detect closely located bars:can detect closely situated,parallel bars with 1.5 diameter gap;
3. Unlimited cyberscan:can scan object with unlimited size,and display the thickness

of cover concrete and bars distributing simultaneously;
4. Actual distributing map of bars:can out put the actual distributing map of bars

after several times scanning;
5. Transverse Section Bars Distributing Map: Can output the transverse section map of bars distributing;
6. Test data may be transferred to computer via USB port, allowing real time analysis of data;
7. Rechargeable lithium battery; convenient, value for money, and environmentally friendly.

Model

ZBL-R800

ZBL-R650

ZBL-R630A

ZBL-R630

ZBL-R620

Protective layer thickness range (mm)

φ6~φ50

φ6~φ50

φ6~φ50

φ6~φ50

φ6~φ50

Max range(mm)

First range

3~98

6~90

3~98

6~90

6~90

Second range

3~196

10~180

3~196

10~180

10~180

Max allowed error

±1(mm)

3~79

6~70

3~79

6~79

6~79

±2(mm)

57~119

51~110

57~119

60~119

60~119

±4(mm)

70~196

70~180

70~196

70~180

70~180

Applicable range(mm)

φ6~φ50

φ6~φ32

φ6~φ50

φ6~φ32

φ6~φ32

Max allowed error

for diameters measurement

±1

Common type


Closely bars type


Transverse section bars


×

Grid type


×

Signal wave

×

Real time display

×

Scan range

Borderless

Data correction

Automatic

Manually

×

Data transfer

U disk

USB

U disk

USB

Wireless transfer


×


×

LCD

160×128

320×240

160×128

Power

Built-in battery

DC:9V 5 batteries

Size (mm)

212×134×50

190×135×52

212×134×50

190×135×52

Weight(kg)

0.9

1.1

0.9

0.9

0.7

Cheap concrete reinforcement detector for sale
