TP304 / TP304L TP316 / TP316L Corrugated Low Fin Tube / Fintube

TP304 / TP304L , TP316 / TP316L , Austenitic Stainless Steel Corrugated Low Fin Tube

Quick Detail:

General Low Fin Tubes Production Capacity	Specifications of Low Fin Tubes('N' Fins)
Finning Facility: 10 finning machines; Daily capacity up to 3000 meters;	Tube OD: 12.7 mm~25.4mm Tube Length: 18 meters max. Fin Height: 1.2 mm ~2.77mm Fin Thickness: appr. 0.3mm Fin Pitch: 30 FPI /28 FPI/ 26 FPI/ 36 FPI /43 FPI

Description:
Manufacturing process: The fins are rolled out of outer wall of the plain tubes by a pass roller. Tubes and fins are in same piece tube. We call it “N” fin type.

Tube Materials:
ASTM A213 / A213M :Seamless Ferritic & Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A312/ A312M : Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A269/ A269M :Seamless and Welded Austenitic Stainless Steel Tubing for General Service

Delivery Range of Low Fin Tubes
We can provide the integral low fin tubes with un-finned section gaps( 5mm Min.) in the middle of core tube OR bent with designed Bend Radius.

Quality Test:
The integral low fin tube quality is assured by hydrostatic or pneumatic tests, eddy current tests & MARCO tests in order to verify design specifications.
Acceptance Ceritia:
WOLVERINE / HPT / GEWA-K & GEWA-KS

Delivery Condition:
Tube ends are square cut, free burrs, internally dried and air blown clean, externally coated with varnish.
The desiccants are put into the each package for continental transportation.

Applications:
The Integral Low Finned Tubes find the preference in the following industrial sectors:

Heating systems
Ventilation systems
Refrigeration and climate control systems
Mechanical engineering
Automotive manufacturing
Chemicals and pertrochemical and power plant technology

Specifications:
Tube and fins consist of same tube and materials as carbon steel , low-alloy steels , stainless steel , brass , copper , cooper-nickel alloys , aluminum bronze , nickel alloys , titanium etc...

Plain tube (mm)	Finned section dimensions (mm)				Ratio	De
D×t	Tp	dd	dr	di	η	mm
19×2	0.8	18.8	17	134	2.8	17.9
19×2	1	18.8	16.8	13.4	2.5	17.8
19×2	1.25	18.8	16.6	13	2.2	17.8
19×2	1.5	18.8	16.6	13	2	17.7
19×2	2	18.8	16.4	13	1.7	17.5
25×2.5	0.8	24.8	23	18.8	2.8	23.9
25×2.5	1	24.8	22.6	18.8	2.75	23.7
25×2.5	1.25	24.8	22.3	18	2.5	23.6
25×2.5	1.5	24.8	22.3	18	2.2	23.5
25×2.5	2	24.8	22	18	1.8	23.4
25×2.5	2.5	24.8	22	18	1.6	23.3
D------Outside diameter of plain end section Dof----Diameter of top fins Dr-----Root diameter of finned section Di-----Inside diameter of finned section T------Wall thickness of plain end section Tp-----Fin pitch De----Equivalent diameter of finned tube L------Plain tube end length
Please email us for more information.

Product Tags:


*From:	Your email address is incorrect!
*To:	JIANGSU RELIANCE THERMAL EQUIPMENT CO., LTD
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Low Fin Tube
Brand Name:	Reliance
Model Number:	LF
Certification:	CE,ISO...
Place of Origin:	China.Imported materials are available
MOQ:	N/A
Price:	N/A
Payment Terms:	T/T, L/C
Supply Ability:	Daily capacity up to 5,000 Meters
Delivery Time:	Ex-work with 5 weeks after order.
Packaging Details:	(1) All integral low fin tubes are packed in hexagonal bundles. (2) Steel frame case sealed by plywoods; 3: Solid fumigated seaworthy wooden box.
Company Type:	Manufacturer, Importer & Exporter
Fin Tube Type:	Low Fin Tubes
Fins Type:	Integral, N Type
Origin:	China
Nearest Port:	Shanghai Port, China
Acceptance Ceritia:	WOLVERINE, HPT, GEWA-K & GEWA-KS
