ASTM Standard Seamless Stainless Steel Round Pipe ISO Certification

ASTM Standard Seamless Stainless Steel Round Pipe ISO Certification

grade: 304/304l.316;316L,310S,321,904L

OD: 1/8" to 10"

Thickness :SCH10-SCH160

Length: 6m-11m

Description:

Item	stainless steel pipe, stainless steel tube
Material	stainless steel
Grade	304, 304L, 316, 316L, 316Ti, 317, 317L, 321, 309S, 310S, 904L
Standard	ASTM, AISI, GB, DIN, JIS, EN
Surface	Black, Bright, Polished, Hair Line, etc.
Shape	Round, Square
Type	Seamless, Welded
Out Diameter	6mm-630mm
Wall Thk.	1mm--60mm
Length	Max. 12000mm
Productivity	5000 tons/month
Packing	Standard export packages, custom suffocating free.
Payment	Usually 30% of the amount by T/T as deposit , and the balance 70% by T/T after got the copy B/L
Delivery Time	within 5-10 days from confirmed order.
MOQ	1 ton
Origin	China(Mainland)
Note	stainless steel pipes/tubes can be made according to the customers' requirements.

Applications:

petrochemical industry, beverage and food industry, printing and dyeing, paper and sugar making, environment protection apparatus, heat exchanger, apparatus and physical instrument, medical treatment, furniture, kitchen utensils, etc.

Specifications:

Chemical Compostion of 316L

C	Si	Mn	P	S	Cr	Ni	Mo
<=0.03	<=1.00	<=2.00	<=0.035	<=0.03	16.00-18.00	12.00-15.00	2.0-3.0

Mechanical properties

Tensile strength (Mpa) 620 MIN The yield strength (Mpa) 310 MIN

The elongation (%) for 30 MIN Covers an area of 40 MIN (%)

Competitive Advantage:

1, good price and high quality

2, 5000 tons stainless steel pipes in stock

3. we have a factory in Wen zhou, our produce period is short

4, 12 years export experience

316L seamless stainless steel round pipe

316L industrial-strength stainless steel tube

Thickness: 3mm

Outer Diameter: 42mm

Welding line type:ERW

Name	Stainless Steel Seamless & Welded Tube &Pipe
Standard	ASTM A554, A249, A269 and A270
Material Grade	201: Ni 0.8%~1%
	202: Ni 3.5%~4.5%
	304: Ni 8%, Cr 18%
	316: Ni 10%, Cr 18%
	316L: Ni10%~14%
	430: Cr16%~18%
Outer Diameter	customized
Thickness	1.0- 3.0mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/- 0.2mm
	b) Thickness: +/- 0.02mm
	c) Length: +/- 5mm
Surface	180G, 240G, 320G Satin / Hairline 400G, 600G Mirror finish
Application	handrail, railing, staircase, weld mesh screen, door, window, balcony, fence, bench, furniture, etc
Test	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Chemical Composition of Material	Material Composition	201	202	304	316	316L	430
	C	≤0.15	≤0.15	≤0.08	≤0.08	≤0.035	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤ 0.045 ≥30%	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030	≤0.030
	Cr	13-15	14-17	18-20	16-18	16-18	16-18
	Ni	0.7-1.1	3.5-4.5	8-10.5	10.0-14.0	10.0-14.0	**
	Mo	**	**	**	**	2.0-3.0	**
Mechanical Property	Material Item			201	202	304	316
	Tensile Strength			≥535	≥520	≥520	≥520
	Yield Strength			≥245	≥205	≥205	≥205
	Extension			≥30%		≥35%	≥35%
	Hardness (HV)			<105	<100	<90	<90

Production Machines

Product Tags:

seamless stainless steel tube

astm stainless steel pipe

ASTM Standard Seamless Stainless Steel Round Pipe ISO Certification

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Stainless Steel Seamless Tube
Brand Name:	TISCO,BAO STEEL
Model Number:	316L
Certification:	SGS,ISO
Place of Origin:	CHINA
MOQ:	5Ton
Price:	3750 USD/Ton
Payment Terms:	T/T or L/C
Supply Ability:	5000 Tons every month
Delivery Time:	5-10 days according to the quantity
Packaging Details:	Export packing
Length:	6-11meter
type:	seamless pipe
OD:	10-325mm
thickness:	SCH10 - SCH 160
company type:	factory and trading
Grade:	304,304L,310S,316L,321,904L,S32760.etc
