Product introduction:
Sensor signal amplifier sensor with a small precision signal
amplifying circuit, inside the line voltage, constant current
bridge, current to voltage conversion, impedance matching, linear
compensation and temperature compensation of, the mechanics were
converted into standard, current and voltage output signal, 4 ~
20mA, 0 ~ 10mA, 0 ~ 5V, 1 ~ 5V direct and automatic control device
interface or with the computer networking, transmitter with
standard signal redeployment of zero, redeployment of gain of
function.
Wires indication :
1 - power + (red)
2- Common end (green)
3 - signal + (yellow)
Main technical index:
Input: mV level voltage signal
Output: 1.5 mV/V or
0 ~ 5V, 1 ~ 5V, 0 ~ 10mA, 4 ~ 20mA
Excitation voltage: 10V or 12V, 15V, 24V (DC)
Operating temperature: -20 ~ 80 oC
![]() |
