371hp Howo 8x4 tipper truck / dumper truck HW76 cab with one berth 7m length

Categories Heavy Duty Dump Truck
Brand Name: SINOTRUK HOWO
Model Number: ZZ3317N3067
Certification: ISO/CCC
Place of Origin: China
MOQ: 1set
Price: USD45000-50000/set
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200sets/month
Delivery Time: 20-30 work days after receiving deposite
Packaging Details: Nude, but with wax sprayed
Product Name: Dump Truck
Condition: New
Color: Optional
Drive type: 8x4
Engine power: 371hp
Cambin: HW76 with one berth
Cargo body(CBM): 28.54
Application: transportation with dumping function
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

371hp Howo 8x4 tipper truck / dumper truck HW76 cab with one berth 7m length

Specifications:


Howo 8x4 Dump Truck
Chassis ModelZZ3317N3067
Production Yearnew truck. (main market in africa)
CabinHW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner , with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.
Engine

Make: SINOTRUK

Diesel 4-stroke direct injection diesel engine

Engine model: WD615.47, Euro 2, 371 HP

6-cylinder in-line with water cooling, turbo-charging and intercooling

Displacement: 9.726 L

Transmission

HW19710, 10F & 2R, with PTO

Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)

SteeringZF power steering, modol ZF8098, hydraulic steering with power assitance
Front Axle

HF9, 2x9000 KGS

Steering with doubleT-cross section beam

Rear Axle

HC16, 2x16000 KGS

Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.

Ratio:5.73

Propeller ShaftDouble universal joint propeller shaft with gear-shaped coupling flange
Chassis

Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members

Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer

Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer

Brake

Service brake: dual circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels

Auxiliary brake: engine exhaust brake

Electrics

Operating voltage: 24 V, negative grounded

Starter: 24 V, 5.4 Kw

Alternator: 3-phase, 28 V, 1500 W

Batteries: 2 x 12 V, 165 Ah

Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light

Tyres315/80R22.5, Tubeless tires with one spare tire.
Fuel Tank300L
Cargo Body7300*2300*1700 mm, 28.54 CBM, Floor 8 mm Side 6 mm, front lifting.
Overall Dimension10100*2550*3500 mm

Description:

Now we have ISO 9001:2000 and CE certificate. we possesses the most advanced domestic designs of special vehicles, and we can design and produce vehicles according to different requirements of customers. Most of our products and technology are national scientific and technological projects, filling the blank of domestic products, being substituted for import and having obtained national patents and awards of national scientific and technological progress. Especially the design and production of our wrecker has reached internationally advanced level

.

Applications:

It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.


Competitive Advantage

1. Sinotruk dump truck adopt many key technologies both from home and abroad,and it can achieve the best design and be in good conditions.

2. Humanization.easy and convenient to drive,there are many key close to touch,and it save human labors and also can make the drive focus on the driving

3. Low oil consumption.Sinotruk adopt the engine that combin the MAN and steyr technolgoy,it has the perfect oil performance.

4. Load more.with using our truck,it can load more goods in safe.
