PTFE ( PTFE ) is the mostly consumed category of florin plastics, Which has the lowest coefficient of

friction in all the engineering plastics, Whose long-term working temperature can reach 200 to 260℃. It

has the excellent chemical corrosion-resistance, which is able to endure All kind of chemistry material.

And it has rather good electricity-resistance, which is not affected by the temperature and is called“ Kind

of plastics”.

Specifications:

Description:

1. Material: PTFE

2. Color: White or others

3. Working temperature: -180 ~ 260 degree (with/without CF/GF filled)

4. Processing: Machine or by mold

5. Sizes: As requirement

We supply special compounds filled ptfe products in order meet specific applications requirements according to end use. For example, glass fiber, carbon fiber, MoS2, Graphite, Bronze and so on.

Features of glass fiber:

1. Increase compressive strength, rigidity and wear.

2. Reduces creep and cold flow

3. Minimal effect on chemical and electrical properties

Features of carbon:

1. Increases compressive strength, hardness, wear, and load properties.

2. Good chemical resistance

3. Various types and amounts of carbon can be added to alter conductivity

Features of graphite:

1. Reduces coefficient of friction

2. Reduces initial wear

3. Increases strength

Features of Molybdenum Disulfide:

1. Increases hardness, stiffness, and wear

2. Minimal effect on chemical and electrical properties

Features of Bronze:

1. Increases hardness and wear resistance

2. Increases dimensional stability and compressive strength

3. Not suitable for corrosive or electrical applications

Applications:

1. Automotive Part

2. Motorcycle Part

3. Pump Parts

4. Locomotive Parts

5. Machinery Parts

6. Tool Parts

7. Industrial parts

Competitive Advantage:

XIAYI, founded in 2006, was set up in a beautiful city Ningbo, which is closed to Ningbo seaport and airport. XIAYI is a specialized factory that is engaged in producing auto spare parts, designing and manufacturing electromechanical & machinery parts and related automatic equipment. XIAYI has a strong R&D team with full of creative spirit. XIAYI develop new products and new equipment every year and was awarded two patents of utility model and invention patents.

The products include shock absorber piston, rod guider, base valve, oil seal, piston rod, bracket, spring seat, valves, guide pipe, bearing bush, copper bush, guide ring, PTFE ring and gasket, in addition XIAYI design and manufacture automatic machine such as banding machine and groove cutting machine.

As a manufacturer, XIAYI insists on pursuing better quality on and on. We control the quality from raw material to assure the consistency from one batch. We have carried out an integrated production system which is based on quality focus. We refer to the rigorous four aspects ( material importing control→ production line control→ QC department control→ logistic department control ) and quality control system to make sure all the products are intact before delivery.

As a seller, our products are exported to the whole world and sold nationally for more than 8 years. About 30% parts are exported to USA, Germany, France, Canada, Brazil, India, Malaysia etc., have set up good relationship with the customers from home and abroad. We have an intelligent marketing team who are exploring new markets, developing potential customers, solving problems and serving customers with orders well. We firmly believe that we are a competitive and friendly cooperator and our goal is for mutual benefit and long-term cooperation. XIAYI persons will always welcome customers from all over the world to visit and negotiate.
