300W Outdoor Network Cabinet Heat Exchanger Low Noise ISO9001 CE Certification
Quick Details:
| Place of Origin: Shenzhen, China (Mainland) | Rated Heat Exchange Capacity: 30W/K |
| Brand Name: ESTEL | Rated Heating Capacity:300W |
| Model: HE06-30SEH/T | Input Voltage: DC48V |
| Product Name: Outdoor Telecom Cabinet Heat Exchanger | Rated Input Current: 0.95A |
| Certification: ISO9001, CE, 3C, FCC, TLC | Rated Input Power: 46W |
| Protection Level: IP55 | Noise: 50dB |
| Installation Mode: top mounted | Dimension W×D×H: 482.6×500×180 mm |
| Support OEM | Type: air to air heat exchanger |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | T/T, L/C, etc |
| Supply Ability: | 12,000 sets per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | carton + foam + wooden case +pallet |
1. Technical Parameters
| Model | HE06-30SEH/T |
| Performance Parameters | |
| Rated Voltage (V) | DC48V |
| Rated Current (A) | 0.95 |
| Heat Exchange Capacity (W) | 300 |
| Heater Power (W) | 300 |
| Rated Power (W) | 46 |
| Circulation Air Volume (m3/h) | 200 |
| Noise (dB(A)) | 50 |
| Refrigerant | Mixed Liquid |
| Working Temperature | -20°C ~ 55°C |
| Mechanical Parameters | |
| Installation Mode | Top Installed |
| Height (mm) | 180 |
| Width (mm) | 482.6 |
| Depth (mm) | 500 |
| Controller Parameters | |
| Working Voltage (V) | DC36~72 |
| Working Temperature and Humidity | -20°C ~ +80°C, <90%RH |
| Temperature Control Accuracy (°C) | 0.1 |
| Power Consumption (W) | 5 |
| Communication Mode | Dry contact,RS485, RS232, GPRS |
2. Description
The cabinet heat exchanger is designed for outdoor cabinet and control cabinet. It is applicable for the scenarios where internal equipment of the cabinet emits a large quantity of heat and the normal operating temperature of internal equipment is higher than the environment temperature and where the indoor environment needs to be isolated from the outdoor completely.
The heat exchanger for outdoor cabinet adapts to the harsh environment. The complete isolation between the indoor environment and the outdoor environment can prevent the dust, hazardous gases, and humid gases from entering the cabinet, thus ensuring the internal cleanliness of the cabinet.
3. Application
The cabinet heat exchanger is widely used for outdoor telecom cabinet, outdoor battery cabinet, outdoor UPS cabinet, outdoor power cabinet, electric cabinet and industry cabinet,etc.
(1) Independent energy saving control technology greatly reduces working energy consumption;
(2) LCD control board provides easy installation and maintenance;
(3) Perfect monitoring function, effective monitoring and management on air conditioner operation;
(4) Integrated design, easy for installation and maintenance;
(5) Protection Level: IP55, anti- corrosion, long service life;
(6) Using DC high efficient fans, greatly lower the product noise, environment friendly;
(7) Good energy saving performance, short investment payback period;
(8) Long service life: more than 10 years, easy maintenance and low cost;
(9) With RS485 remote monitoring interface, fault detection and alarm can be transmitted to monitoring center through controller.
Wiring Ports:
0V -48V: power supply input (voltage input: DC36 - 65V)
A+ B- SGND: RS485 communication interface
AL1 AL2: general alarm output
F+ F- : auxiliary direct ventilation control output (output voltage: DC48V)
7. Packing and Shipping
Our Delivery Agent
The goods can be shipped by sea, by air, by courier, by land, by train, etc.
Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
